032F1156

Part Number: 032F1156
032F1156
Manufacturer
Danfoss
Part number
032F1156
Category

Product Information

Extended Description

032F1156 Danfoss: Body material: Brass, Kv value [m=C2=B3/h]: 0.270, Packing format: Multi pack
Gross weight
0.216 Kilogram
Net weight
0.159 Kilogram
Volume
0.854 Liter
EAN
5702422041023
Actuator system [mm]
13.5 mm
Ambient temperature
-40 - Coil dependent
Approval
C UL US LISTED,EAC,LLC CDC TYSK
Body material
Brass
China RoHS compliance
Yes exceed limitations
Coil
No
Contain batteries
No
Cv value [gal/min]
0.31 gal/min
Direction
Straightway
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(a),6(c)
Function
NC
Inlet connection type
Solder, ODF
Inlet size [in]
1/4 in
Kv value [m=C2=B3/h]
0.27 m=C2=B3/h
Lubricants compatibility
AB,MO,PAG,PAO,POE,PVE
Manual operation option
No
Max. Working Pressure [bar]
45.2 bar
Max. Working Pressure [psig]
655 psig
MaxOPD[bar] 10W AC
38 bar
MaxOPD[psi] 10W AC
550 psi
Medium temp. range note
Defrost max 130=C2=B0C/265=C2=B0F
Medium temperature range [=C2=B0C] [max]
105 =C2=B0C
Medium temperature range [=C2=B0C] [min]
-40 =C2=B0C
Medium temperature range [=C2=B0F] [max]
221 =C2=B0F
Medium temperature range [=C2=B0F] [min]
-40 =C2=B0F
MinODP [bar]
0 bar
MWP [bar] PED compliant
49 bar
Orifice size [mm]
3.3 mm
Outlet connection type
Solder, ODF
Outlet size [in]
1/4 in
Packing format
Multi pack
Parts Program name
EVR
Product accessories
Solenoid valve accessories
Product group
Solenoid valves
Product Name Description
Solenoid valve
Quantity per packing format
24 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Refrigerants
R1234yf,R1234ze(E),R125,R134a,R152a,R22,R290,R32,R404A,R407A,R407C,R407F,R407H,R410A,R413A,R417A,R422A,R422B,R422D,R438A,R442A,R444B,R447A,R447B,R448A,R449A,R449B,R450A,R452A,R452B,R454A,R454B,R454C,R455A,R463A,R507A,R512A,R513A,R513B,R515A,R515B,R516A,R600,R600a
SCIP dossier no.
52f475eb-6026-442a-932e-863e4660eac8
SCIP dossier product name
EVR 2-8/EVO 100-102
Serviceable
Solenoid valve spare parts
Type
EVR 3
Type designation
Solenoid valve, Solder
UK RoHS compliance
Out of scope
UL approved refrigerants
R125,R134a,R152a,R22,R290,R404A,R407A,R407C,R407F,R407H,R410A,R417A,R422A,R422B,R422D,R438A,R442A,R447B,R448A,R449A,R449B,R450A,R452A,R463A,R507A,R513A,R513B,R515A,R515B,R600,R600a,R1234ze(E),R32,R452B,R454B
UL evaluated
Yes
Valve operation
Direct
Enhanced reliability and savings with EVR - Release 2017 Solenoid valve Type EVR 2 - EVR 40 Spare parts and accessories, Solenoid valve Types EVR 2 - EVR 40 (Version 1 and Version 2) Solenoid valve. Types EVR 2 - EVR 22 (For EVR2-3: 032Fxxxx / EVR 4-22: 032Lxxxx) SERVICE GUIDE. Solenoid valve. Types EVR 2 - EVR 22 (For EVR2-3: 032Fxxxx / EVR 4-22: 032Lxxxx) SERVICE GUIDE. Solenoid valve. Types EVR 2 - EVR 22 (For EVR2-3: 032Fxxxx / EVR 4-22: 032Lxxxx) Solenoid valve Type EVR 2 - EVR 40 Version 2 Danfoss EU-UK 033F0688.AJ CQC 11002055287 Danfoss MD 033F0687.AH Danfoss MD 033F0695.AA Danfoss MD 033F1035.AQ DNV TAA0000085 Rev. 5 UL MH7648 EVR2_3_NC_032F1204, 032F811831, 032F811931 EVR 3 ODF-ODF 1/4in EVR 3 ODF-ODF 1/4in
