042N0267
Part Number: 042N0267
Product Information
Extended Description
042N0267 Danfoss: Product Type: Spare part, Used for product: 9-22 Coil AB/AC, Type designation: Cable plug, Cable plug
Gross weight
0.022 Kilogram
Net weight
0.012 Kilogram
Volume
0.043 Liter
EAN
5702423205905
Ambient temperature range [°C] [max]
90 °C
Ambient temperature range [°C] [min]
-40 °C
Ambient temperature range [°F] [max]
194 °F
Ambient temperature range [°F] [min]
-40 °F
Approval
CE,UKCA
Body type
Translucent
Cable diameter [in] [max]
0.32 in
Cable diameter [in] [min]
0.24 in
Cable diameter [mm] [max]
8 mm
Cable diameter [mm] [min]
6 mm
CE evaluated
Yes
China RoHS compliance
Out of scope
Conductor size, max. [mm2]
1.5 mm²
Contact material
CuZn (Cu/Sn plated)
Contact resistance max. [mOhm]
15 mOhm
Contacts
2 + PE
Contain batteries
No
Electrical connection form
Industrial form
Enclosure rating IP
IP65
EU RoHS compliance
Out of scope
Gasket material
NBR
Gasket type
Profiled
LED colour
Red
Operating current max. [A]
16 A
Packing format
Multi pack
Product group
Solenoid coil accessories
Product Name Description
Cable plug
Quantity per packing format
100 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
SCIP dossier no.
23785618-b379-4da7-a913-ecd40c8fae6d
Supply voltage [V] AC
24 V
Supply voltage [V] DC
24 V
Tolerance
± 10%
Type
Spare part
Type designation
Cable plug
UK RoHS compliance
Out of scope
Used for product
9-22 Coil AB/AC
