042N0806
Part Number: 042N0806
Product Information
Extended Description
042N0806 Danfoss: Electrical connection: DIN Spade, Enclosure rating IP: IP00
Gross weight
0.062 Kilogram
Net weight
0.055 Kilogram
Volume
0.092 Liter
EAN
5702423071197
Actuator size
9 mm
Ambient temperature range [°C] [max]
50 °C
Ambient temperature range [°C] [min]
-40 °C
Ambient temperature range [°F] [max]
122 °F
Ambient temperature range [°F] [min]
-40 °F
Coil connection
DIN Spade
Coil fastening
Finger screw
Colour
Black
Contain batteries
No
EEE category
5 small equipment (any external dimension 50 cm)
Electrical connection
DIN Spade
Electrical connection size
6.3 mm x 0.8 mm
Electrical connection standard
EN175301-803
Electrical connector
3 x spades
Enclosure rating IP
IP00
EU RoHS compliance
Out of scope
In scope of WEEE
Yes
Packing format
Multi pack
Parts Program name
EV210A,EV220A,EV310A
Power consumption [W] DC
5 W
Product accessories
Solenoid coil accessories
Product group
Solenoid valves
Product Name Description
Solenoid coil
Quantity per packing format
24 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
SCIP dossier no.
23785618-b379-4da7-a913-ecd40c8fae6d
SCIP dossier product name
Solenoid coils
Serviceable
No
Supply voltage [V] DC
12 V
Type
AB012D
Type designation
AB012D
Solenoid coil Type AB, AM, AC, AK, AL, AP, BB, BA, BC and BD
Danfoss UA 8505
Danfoss UA 8505
Danfoss UA 8505
Danfoss UA 8505
Danfoss UA 8505
Danfoss UA 8505
Danfoss UA 8505
Danfoss UA 8505
Danfoss UA 8505
Danfoss UA 8505
Coils for Solenoid Valves, type AB012C, AB012D, AB110C, AB240C
AB coil - DIN spade
