042N2216
Part Number: 042N2216
Product Information
Extended Description
042N2216 Danfoss: Enclosure rating IP: IP00, Coil connection: DIN Spade, Actuator size: 9 mm
Gross weight
0.12 Kilogram
Net weight
0.111 Kilogram
Volume
0.1 Liter
EAN
5702424536534
Actuator size
9 mm
Ambient temperature range [°C] [max]
50 °C
Ambient temperature range [°C] [min]
-40 °C
Ambient temperature range [°F] [max]
120 °F
Ambient temperature range [°F] [min]
-40 °F
Approval
LLC CDC TYSK
Coil connection
DIN Spade
Colour
Black
Contain batteries
No
EEE category
5 small equipment (any external dimension 50 cm)
Electrical connection size
6.3 mm x 0.8 mm
Enclosure rating IP
IP00
In scope of WEEE
Yes
Packing format
Industrial pack
Power consumption [W]
6 W
Product group
Solenoid valves
Product Name Description
Solenoid coil
Quantity per packing format
112 pc
Supply voltage [V] DC
24 V
Type
AL024D
Type designation
AL024D
