060L113166
Part Number: 060L113166
Product Information
Extended Description
060L113166 Danfoss: Reset function: Manual Max, Contact function: 2 SPST(NC), Sensor type: Remote bulb, Capillary tube length [mm]: 1000, Enclosure rating IP: IP30
Gross weight
0.686 Kilogram
Net weight
0.62 Kilogram
Volume
1.993 Liter
EAN
5702428016490
Amb. Temp. Note
80 °C/176 °F for max 120 min
Ambient temperature range [°C] [max]
65 °C
Ambient temperature range [°C] [min]
-40 °C
Ambient temperature range [°F] [max]
150 °F
Ambient temperature range [°F] [min]
-40 °F
Approval
CCC,CE,CMIM,EAC,LLC CDC EURO-TYSK,LVD,PZH,RINA,RMRS,RoHS China,c UL us UL873, CS C22.2
Cap. tube length fraction [in]
39 3/8 in
Capillary tube length [mm]
1000 mm
CE evaluated
Yes
Charge type
Adsorption
China RoHS compliance
Yes
Contact function
2 SPST(NC)
Contact rating
AC15=10 A, 400 V,AC1=16 A, 400 V,AC3=16 A, 400 V,DC13=12 W, 220 V,LR=112 A, 400 V
Contain batteries
No
Diff. @ Max. range setting [K]
14 K
Diff. @ Max. range setting[°C]
14 °C
Diff. @ Min. range setting [K]
14 K
Diff. @ Min. range setting[°C]
14 °C
Differential type
Fixed
Electrical connection
Rubber cable gland
Electrical connection size
6-14 mm
Electrical spec. standard
EN 60947-5
EN 60947 electrical properties
Insulation: 400V,Pollution degree: 3,Rated impulse voltage: 4 kV,Short circuit prot, fuse: 16A
EN 60947 wiring properties
Flex, ferrules: 0.5-1.5 mm2,Flex, no ferrules: 0.7-2.5 mm2,Solid/stranded: 0.75-2.5 mm2
Enclosure rating IP
IP30
Enclosure rating Nema (~)
1
Equipment
Right side cap.tube 2 m
EU RoHS compliance
Yes
EU RoHS exemption clause
No
Max. sensor temperature [°C]
150 °C
Max. sensor temperature [°F]
302 °F
Packing format
Multi pack
Product accessories
Switches accessories
Product description
Thermostat
Product group
Switches and thermostats
Product Name Description
Thermostat
Quantity per packing format
20 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Reset function
Manual Max
Reset function, left side
Manual Max
Reset function, right side
Manual Max
SCIP dossier no.
be15a44e-80b1-41bd-9578-c8ff1cd7b9f3
Sensor size (Ø x L) [in]
3/8 x 4 1/2 in
Sensor size (Ø x L) [mm]
9.5 x 115 mm
Sensor type
Remote bulb
Serviceable
No
Temp. range left side [°C] [max]
120 °C
Temp. range left side [°C] [min]
60 °C
Temp. range left side [°F] [max]
250 °F
Temp. range left side [°F] [min]
140 °F
Temp. range right side [°C] [max]
180 °C
Temp. range right side [°C] [min]
100 °C
Temp. range right side [°F] [max]
350 °F
Temp. range right side [°F] [min]
210 °F
Type
KP98
UK RoHS compliance
Yes
UL approval file name
E31024
UL evaluated
Yes
