060L116066

Part Number: 060L116066
060L116066
Manufacturer
Danfoss
Part number
060L116066
Category

Product Information

Extended Description

060L116066 Danfoss: Reset function: Manual Min, Contact function: SPDT, Sensor type: Double contact remote sensor, Capillary tube length [mm]: 5000, Enclosure rating IP: IP30
Gross weight
0.616 Kilogram
Net weight
0.552 Kilogram
Volume
1.87 Liter
EAN
5702428016544
Alarm Signal
Falling
Amb. Temp. Note
80 °C/176 °F for max 120 min
Ambient temperature range [°C] [max]
65 °C
Ambient temperature range [°C] [min]
-40 °C
Ambient temperature range [°F] [max]
150 °F
Ambient temperature range [°F] [min]
-40 °F
Approval
BV,CCC,CE,CMIM,DNV,EAC,GL,LLC CDC EURO-TYSK,LR,LVD,PZH,RINA,RMRS,RoHS China,c UL us UL873, CS C22.2
Cap. tube length fraction [in]
196 7/8 in
Capillary tube length [mm]
5000 mm
CE evaluated
Yes
Charge type
Adsorption
China RoHS compliance
Yes
Contact function
SPDT
Contact rating
AC15=10 A, 400 V,AC1=16 A, 400 V,AC3=16 A, 400 V,DC13=12 W, 220 V,LR=112 A, 400 V
Contain batteries
No
Differential (FS) [K]
4 K
Differential type
Fixed (max. value)
Electrical connection
Rubber cable gland
Electrical connection size
6-14 mm
Electrical spec. standard
EN 60947-5
EN 60947 electrical properties
Insulation: 400V,Pollution degree: 3,Rated impulse voltage: 4 kV,Short circuit prot, fuse: 16A
EN 60947 wiring properties
Flex, ferrules: 0.5-1.5 mm2,Flex, no ferrules: 0.7-2.5 mm2,Solid/stranded: 0.75-2.5 mm2
Enclosure rating IP
IP30
Enclosure rating Nema (~)
1
EU RoHS compliance
Yes
EU RoHS exemption clause
No
Factory setting (FS) [°C]
2 °C
Factory setting type
Dedicated
Max. sensor temperature [°C]
80 °C
Max. sensor temperature [°F]
176 °F
Packing format
Industrial pack
Parts included
screws,Wall bracket
Product accessories
Switches accessories
Product description
Thermostat
Product group
Switches and thermostats
Product Name Description
Thermostat
Quantity per packing format
12 pc
Reset function
Manual Min
Sensor size (Ø x L) [in]
13/32 x 3 3/8 in
Sensor size (Ø x L) [mm]
10 x 85 mm
Sensor type
Double contact remote sensor
Serviceable
No
Type
KP73
UK RoHS compliance
Yes
UL approval file name
E31024
UL evaluated
Yes
017-420166
Switches accessories, Sensor Holder Kit
017-420466
Switches accessories, Clamping Band Ass'y
017-422066
Generic accessories, Tube Gland For RT
060-003166
Switches accessories, Protective Cap For KP Single
060-033066
Switches accessories, IP55 Enclosure For KP (Single)
060-062866
Switches accessories, IP55 Transparent Enclosure
060-105566
Switches accessories, Wall Bracket Straight
060-105666
Switches accessories, Wall Bracket Angle
060-109766
Switches accessories, Top Plate For KP Single
Switches and thermostats - Industrial Refrigeration product group catalogue Thermostat type KP Thermostat Type KP, Spare parts and accessories Thermostat KP 61 – KP 85 Thermostat type KP Danfoss CCC 2024010305641303 Danfoss EU 060-9650AF UL E31024 Pressure switches & Thermostats Danfoss MD 060-9638.AA BV SMS.W.II-2179-C.0 BV 02281-K0 BV DNV TAA000026F Rev.01 LR21356588TA RINA ELE086320XG-001 Thermostat, KP73 060L116066 KP 61 - KP 81 dimensions, without sensor bulb Thermostat, KP73 060L116066 Thermostat, KP73 060L116066 KP73 Thermostat KP73 Thermostat
