060L128166

Part Number: 060L128166
060L128166
Manufacturer
Danfoss
Part number
060L128166
Category

Product Information

Extended Description

060L128166 Danfoss: Temperature range [°C]: 50 - 100, Reset function: Manual Max, Contact function: SPDT, Sensor type: Rigid sensor, Enclosure rating IP: IP55
Gross weight
0.729 Kilogram
Net weight
0.714 Kilogram
Volume
3.553 Liter
EAN
5715162135037
Amb. Temp. Note
80 °C/176 °F for max 120 min
Ambient temperature range [°C] [max]
65 °C
Ambient temperature range [°C] [min]
-40 °C
Ambient temperature range [°F] [max]
150 °F
Ambient temperature range [°F] [min]
-40 °F
Approval
BV,CCC,CE,DNV,EAC,GL,LLC CDC EURO-TYSK,LVD,PZH,RINA,RMRS,RoHS China,c UL us UL353, CS C22.2,c UL us UL873, CS C22.2
CE evaluated
Yes
Charge type
Adsorption
China RoHS compliance
Yes
Connection for pocket or hose
M 18 x 1.5
Contact function
SPDT
Contact rating
AC15=10 A, 400 V,AC1=16 A, 400 V,AC3=16 A, 400 V,DC13=12 W, 220 V,LR=112 A, 400 V
Contain batteries
No
Diff. @ Max. range setting [K]
5.5 K
Diff. @ Max. range setting[°C]
5.5 °C
Diff. @ Min. range setting [K]
5.5 K
Diff. @ Min. range setting[°C]
5.5 °C
Differential type
Fixed
Electrical conn. comments
Metal cable gland
Electrical conn. Male/Female
Female
Electrical connection
Screwed cable entry
Electrical connection size
Pg 13.5
Electrical connection standard
DIN 40430
Electrical spec. standard
EN 60947-5
EN 60947 electrical properties
Insulation: 400V,Pollution degree: 3,Rated impulse voltage: 4 kV,Short circuit prot, fuse: 16A
EN 60947 wiring properties
Flex, ferrules: 0.5-1.5 mm2,Flex, no ferrules: 0.7-2.5 mm2,Solid/stranded: 0.75-2.5 mm2
Enclosure rating IP
IP55
EU RoHS compliance
Yes
EU RoHS exemption clause
No
Max. sensor temperature [°C]
150 °C
Max. sensor temperature [°F]
302 °F
Packing format
Multi pack
Product accessories
Switches accessories
Product description
Thermostat
Product group
Switches and thermostats
Product Name Description
Thermostat
Quantity per packing format
10 pc
Reset function
Manual Max
Sensor pocket length min. [in]
6 9/16 in
Sensor pocket length min. [mm]
110 mm
Sensor size (Ø x L) [in]
1/2 x 2 1/2 in
Sensor size (Ø x L) [mm]
13 x 63 mm
Sensor type
Rigid sensor
Serviceable
No
Temperature range [°C] [max]
100 °C
Temperature range [°C] [min]
50 °C
Temperature range [°F] [max]
212 °F
Temperature range [°F] [min]
122 °F
Type
KP79
UK RoHS compliance
Yes
UL approval file name
E31024,MH27572
UL evaluated
Yes
Pressure switch and thermostat type KP and KPI Thermostat type KP Thermostats Type KP Thermostat KP 61 – KP 85 Danfoss CCC 2024010305641303 Danfoss EU 060-9650AF UL E31024 Pressure switches & Thermostats Danfoss MD 060-9638.AA BV SMS.W.II-2179-C.0 BV 02281-K0 BV DNV TAA000026F Rev.01 RINA ELE086320XG-001 UL MH27572 Thermostat, KP79_060L127466 KP79 Thermostat M/10 KP79 Thermostat M/10
