061G1006
Part Number: 061G1006
Product Information
Extended Description
061G1006 Danfoss: Contact function: SPDT, Reset function: Manual, Pressure connection type: Flare, Pressure connection size: 1/4 in, Pressure Male/Female: Female, Max. Working Pressure [bar]: 15.0
Gross weight
0.139 Kilogram
Net weight
0.132 Kilogram
Volume
0.441 Liter
EAN
5702428257978
Ambient temperature range [°C] [max]
70 °C
Ambient temperature range [°C] [min]
-20 °C
Capillary tube length [mm]
1000 mm
Contact function
SPDT
Contact rating
AC125V/AC250V,FLA 1-20 A
Contain batteries
No
Electrical conn. comments
3 x Faston terminal 250
Electrical connection
Spade connectors
Max. test pressure [bar] Pe
16.5 bar
Max. Working Pressure [bar]
15 bar
Max. Working Pressure [psig]
218 psig
Mounting options
2 x M4 x 0.7
Packing format
Industrial pack
Pressure connection size
1/4 in
Pressure connection type
Flare
Pressure Male/Female
Female
Pressure range category
Low pressure
Pressure setting OFF [bar]
2 bar
Pressure setting ON [bar]
3 bar
Product accessories
No
Product group
Switches and thermostats
Product Name Description
Compact pressure switch
Quantity per packing format
100 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Refrigerants
R1234yf,R1234ze(E),R134a,R32,R404A,R407A,R407C,R407F,R410A,R448A,R449A,R450A,R452A,R452B,R454A,R454B,R454C,R455A,R507A,R513A
Reset function
Manual
SCIP dossier no.
6450ee16-252d-49df-8f77-4136a47bb857
SCIP dossier product name
T2/TE2
Serviceable
No
Specification key
ETB-X310
Type
ETB
