061G1023
Part Number: 061G1023
Product Information
Extended Description
061G1023 Danfoss: Contact function: SPDT, Reset function: Auto, Pressure connection type: Solder, ODM, Pressure connection size: 2.4 mm, Max. Working Pressure [bar]: 33.0
Gross weight
0.107 Kilogram
Net weight
0.102 Kilogram
Volume
0.295 Liter
EAN
5702428257862
Ambient temperature range [°C] [max]
70 °C
Ambient temperature range [°C] [min]
-20 °C
Approval
UL
Capillary tube length [mm]
1000 mm
Contact function
SPDT
Contact rating
AC125V/AC240V,FLA 20 A
Contain batteries
No
Electrical conn. comments
3 x Faston terminal 250
Electrical connection
Spade connectors
Max. test pressure [bar] Pe
40 bar
Max. Working Pressure [bar]
33 bar
Max. Working Pressure [psig]
478 psig
Mounting options
2 x M4 x 0.7
Packing format
Industrial pack
Pressure connection size
2.4 mm
Pressure connection type
Solder, ODM
Pressure range category
High pressure
Pressure setting OFF [bar]
25 bar
Pressure setting ON [bar]
20 bar
Product accessories
No
Product group
Switches and thermostats
Product Name Description
Compact pressure switch
Quantity per packing format
100 pc
REACH Candidate List substances
No
Refrigerants
R1234yf,R1234ze(E),R134a,R32,R404A,R407A,R407C,R407F,R410A,R448A,R449A,R450A,R452A,R452B,R454A,R454B,R454C,R455A,R507A,R513A
Reset function
Auto
Serviceable
No
Specification key
HTB-3UC04
Type
HTB
UL approved refrigerants
R134a,R404A,R407A,R407C,R407F,R410A,R448A,R449A,R450A,R452A,R507A,R513A
UL evaluated
Yes
