061G1056
Part Number: 061G1056
Product Information
Extended Description
061G1056 Danfoss: Contact function: SPDT, Reset function: Auto, Pressure connection type: Solder, ODM, Pressure connection size: 2.4 mm, Max. Working Pressure [bar]: 25.0
Gross weight
0.111 Kilogram
Net weight
0.105 Kilogram
Volume
0.45 Liter
EAN
5702428257695
Ambient temperature range [°C] [max]
70 °C
Ambient temperature range [°C] [min]
-20 °C
Capillary tube length [mm]
1000 mm
Contact function
SPDT
Contact rating
AC125V/AC250V,FLA 1-6 A
Contain batteries
No
Electrical conn. comments
3 x Faston terminal 250
Electrical connection
Spade connectors
Max. test pressure [bar] Pe
30 bar
Max. Working Pressure [bar]
25 bar
Max. Working Pressure [psig]
362 psig
Mounting options
2 x M4 x 0.7
Packing format
Industrial pack
Pressure connection size
2.4 mm
Pressure connection type
Solder, ODM
Pressure range category
High pressure
Pressure setting OFF [bar]
15 bar
Pressure setting ON [bar]
17 bar
Product accessories
No
Product group
Switches and thermostats
Product Name Description
Compact pressure switch
Quantity per packing format
100 pc
Refrigerants
R134a,R404A,R407A,R407C,R407F,R410A,R448A,R449A,R450A,R452A,R507A,R513A,R1234yf,R1234ze(E),R32,R452B,R454B,R454C,R455A,R454A
Reset function
Auto
Serviceable
No
Specification key
HTB-X3028
Type
HTB
