061G1088
Part Number: 061G1088
Product Information
Extended Description
061G1088 Danfoss: Contact function: SPDT, Reset function: Manual, Pressure connection type: Solder, ODM, Pressure connection size: 2.4 mm, Max. Working Pressure [bar]: 11.0
Gross weight
0.134 Kilogram
Net weight
0.118 Kilogram
Volume
0.445 Liter
EAN
5702428531535
Ambient temperature range [°C] [max]
70 °C
Ambient temperature range [°C] [min]
-20 °C
Approval
CE,PED
Capillary tube length [mm]
1000 mm
CE evaluated
Yes
Contact function
SPDT
Contact rating
AC125V/AC250V,FLA 6 A
Contain batteries
No
Electrical conn. comments
3 x Faston terminal 250
Electrical connection
Spade connectors
Max. test pressure [bar] Pe
16.5 bar
Max. Working Pressure [bar]
11 bar
Max. Working Pressure [psig]
159 psig
Mounting options
2 x M4 x 0.7
Packing format
Industrial pack
Pressure connection size
2.4 mm
Pressure connection type
Solder, ODM
Pressure range category
Low pressure
Pressure setting OFF [psig]
7.1 psig
Pressure setting ON [psig]
21.3 psig
Product accessories
No
Product group
Switches and thermostats
Product Name Description
Compact pressure switch
Quantity per packing format
100 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Refrigerants
R1234yf,R1234ze(E),R134a,R32,R404A,R407A,R407C,R407F,R410A,R448A,R449A,R450A,R452A,R452B,R454A,R454B,R454C,R455A,R507A,R513A
Reset function
Manual
SCIP dossier no.
6450ee16-252d-49df-8f77-4136a47bb857
SCIP dossier product name
T2/TE2
Serviceable
No
Specification key
ETB-X331
Type
ETB
