061H3147

Part Number: 061H3147
061H3147
Manufacturer
Danfoss
Part number
061H3147
Category

Product Information

Extended Description

061H3147 Danfoss: Factory setting [bar]: 28.00, P band max. [bar]: 7.0, Regulation range [bar] Pe [min]: 22.00, Regulation range [bar] Pe [max]: 39.00, Type designation: XGE-6SI-E
Gross weight
0.262 Kilogram
Net weight
0.19 Kilogram
Volume
0.746 Liter
EAN
5702428531603
Ambient temperature range [°C] [max]
55 °C
Ambient temperature range [°C] [min]
-20 °C
Ambient temperature range [°F] [max]
131 °F
Ambient temperature range [°F] [min]
-4 °F
Approval
CE,UKCA
CE evaluated
Yes
China RoHS compliance
Out of scope
Contain batteries
No
Enclosure rating IP
IP65
EU RoHS compliance
Out of scope
Factory setting [bar]
28 bar
Factory setting [psig]
406 psig
Housing
Closed
Identical product
061H3247
Max. Working Pressure [bar]
47 bar
Max. Working Pressure [psig]
681 psig
P band max. [bar]
7 bar
P band max. [psi]
101 psi
Packing format
Industrial pack
Pressure connection notes
with Schrader
Pressure inlet conn. size [in]
1/4
Pressure inlet conn. std.
DIN 8906
Pressure inlet conn. type
Flare
Pressure inlet Internal/Extern
Internal
Product accessories
No
Product group
Electronic controllers
Product Name Description
Fan speed controller
Quantity per packing format
60 pc
Refrigerants
R407H,R410A,R449B
Regulation range [bar] Pe [max]
39 bar
Regulation range [bar] Pe [min]
22 bar
Regulation range [MPa] Pe [max]
3.9 MPa
Regulation range [MPa] Pe [min]
2.2 MPa
Regulation range [psig] Pe [max]
566 psig
Regulation range [psig] Pe [min]
319 psig
Serviceable
No
Supply voltage [V] DC
10 V
Type
XGE-EC
Type designation
XGE-6SI-E
UK RoHS compliance
Out of scope
