061L2200
Part Number: 061L2200
Product Information
Extended Description
061L2200 Danfoss: Supply voltage [V] AC: 24, Frequency [Hz]: 50/60 Hz, Enclosure rating IP: IP54
Gross weight
0.108 Kilogram
Net weight
0.103 Kilogram
Volume
0.091 Liter
EAN
5702428272407
Ambient temperature range [°C] [max]
55 °C
Ambient temperature range [°C] [min]
-20 °C
Ambient temperature range [°F] [max]
131 °F
Ambient temperature range [°F] [min]
-4 °F
Approval
CE,UL,VDE
Cable length [in]
0 in
Cable length [m]
0 m
China RoHS compliance
Out of scope
Class of Insulation
B
Coil mount, recom. torque [Nm] [max]
1.96 nm
Coil mount, recom. torque [Nm] [min]
1.47 nm
Comments
FASTON TAB
Contain batteries
No
Enclosure rating IP
IP54
EU RoHS compliance
Out of scope
Frequency [Hz]
50/60 Hz
Packing format
Industrial pack
Power consumption [W] 50Hz
6 W
Power consumption [W] 60Hz
5 W
Product group
4-way reversing valves
Product Name Description
4-way reversing valve coil
Quantity per packing format
140 pc
REACH Candidate List substances
No
Supply voltage [V] AC
24 V
Type
STF
Type designation
STF-01AB060UA1
UK RoHS compliance
Out of scope
UL approval file name
MH12113
