061N4051
Part Number: 061N4051
Product Information
Extended Description
061N4051 Danfoss: Body material: Polymer
Gross weight
0.128 Kilogram
Net weight
0.122 Kilogram
Volume
0.148 Liter
EAN
5702428269049
Approval
UL
Body material
Polymer
Cable length [in]
23.6 in
Cable length [m]
0.6 m
China RoHS compliance
Out of scope
Class of Insulation
105
Coil
Yes
Coil temperature, max. [°C]
125 °C
Coil temperature, max. [°F]
257 °F
Contain batteries
No
EU RoHS compliance
Out of scope
Frequency [Hz]
50/60 Hz
Max. ambient temperature
80 °C
Packing format
Industrial pack
Parts Program name
EV/PV solenoid valves
Power consumption [W]
7 W
Product accessories
No
Product group
Solenoid valves
Product Name Description
Solenoid coil
Quantity per packing format
100 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
SCIP dossier no.
f8fe2fb6-0750-4373-b03a-5b5988b72210
SCIP dossier product name
Four-way valve(1)
Serviceable
No
Supply voltage [V] AC
230 V
Type
NEV
Type designation
NEV-MOAI513UB1
UK RoHS compliance
Out of scope
UL evaluated
Yes
Wire colour
Blue
