065B7733
Part Number: 065B7733
Product Information
Extended Description
065B7733 Danfoss: FVF DN80 PN16 with Ball Valve mounted on
Gross weight
16.05 Kilogram
Net weight
15.498 Kilogram
Volume
22.349 Liter
EAN
5702421555583
Approval standard
DIN EN 1092-2
China RoHS compliance
Out of scope
Connection size
80
Connection types
Flange
Contain batteries
No
Description
FVF DN80 PN16 with Ball Valve mounted on
Diameter [mm]
80 mm
EU RoHS compliance
Out of scope
Kvs values [mÂł/h]
140 mÂł/h
Label product
Yes
Material
Grey cast iron EN-GJL-250 (GG25)
Media temperature [°C] [Max]
120 °C
Media temperature [°C] [Min]
-10 °C
Medium alternative
Glycolic water up to 50%
Mesh size [mm]
1.18 mm
Number of meshes [n/cm²]
25
Permissible media
District heating/cooling circulation water
Pressure class
PN 16
Pressure nominal [bar]
16 bar
Product group
Auxiliary Products
REACH Candidate List substances
No
Size
DN 80
Strainer type
With draining ball valve
Type
FVF
UK RoHS compliance
Out of scope
065B7817
Screens DN80 PN16-25 Normal+gasket
065B7831
Screens DN80 PN16-25 Fine+gasket
065B7795
FVF-M, Magnetic Insert DN80
065B7801
Drain ball valve FVF-B brass body, DN 65-300
065B7891
FVF gasket
