065B7734
Part Number: 065B7734
Product Information
Extended Description
065B7734 Danfoss: FVF DN100 PN16 with Ball Valve mounted o
Gross weight
27.2 Kilogram
Net weight
23 Kilogram
Volume
90.86 Liter
EAN
5702421555590
Approval standard
DIN EN 1092-2
China RoHS compliance
Out of scope
Connection size
100
Connection types
Flange
Contain batteries
No
Description
FVF DN100 PN16 with Ball Valve mounted o
Diameter [mm]
100 mm
EU RoHS compliance
Out of scope
Kvs values [m³/h]
201 m³/h
Label product
Yes
Material
Grey cast iron EN-GJL-250 (GG25)
Media temperature [°C] [Max]
120 °C
Media temperature [°C] [Min]
-10 °C
Medium alternative
Glycolic water up to 50%
Mesh size [mm]
1.18 mm
Number of meshes [n/cm²]
25
Permissible media
District heating/cooling circulation water
Pressure class
PN 16
Pressure nominal [bar]
16 bar
Product group
Auxiliary Products
REACH Candidate List substances
No
Size
DN 100
Strainer type
With draining ball valve
Type
FVF
UK RoHS compliance
Out of scope
065B7818
Screens DN100 PN16-25 Normal+gasket
065B7832
Screens DN100 PN16-25 Fine+gasket
065B7796
FVF-M, Magnetic Insert DN100-125
065B7801
Drain ball valve FVF-B brass body, DN 65-300
065B7892
FVF gasket
