065B7737
Part Number: 065B7737
Product Information
Extended Description
065B7737 Danfoss: FVF DN200 PN16 with Ball Valve mounted o
Gross weight
123 Kilogram
Net weight
109 Kilogram
Volume
230.4 Liter
EAN
5702421555620
Approval standard
DIN EN 1092-2
China RoHS compliance
Out of scope
Connection size
200
Connection types
Flange
Contain batteries
No
Description
FVF DN200 PN16 with Ball Valve mounted o
Diameter [mm]
200 mm
EU RoHS compliance
Out of scope
Kvs values [mÂł/h]
870 mÂł/h
Material
Grey cast iron EN-GJL-250 (GG25)
Media temperature [°C] [Max]
120 °C
Media temperature [°C] [Min]
-10 °C
Medium alternative
Glycolic water up to 50%
Mesh size [mm]
1.18 mm
Number of meshes [n/cm²]
25
Permissible media
District heating/cooling circulation water
Pressure class
PN 16
Pressure nominal [bar]
16 bar
Product group
Auxiliary Products
REACH Candidate List substances
No
Size
DN 200
Strainer type
With draining ball valve
Type
FVF
UK RoHS compliance
Out of scope
065B7821
Screens DN200 PN16-25 Normal+gasket
065B7835
Screens DN200 PN16-25 Fine+gasket
065B7798
FVF-M, Magnetic Insert DN200
065B7801
Drain ball valve FVF-B brass body, DN 65-300
065B7895
FVF gasket
