065B7751
Part Number: 065B7751
Product Information
Extended Description
065B7751 Danfoss: FVF DN200 PN16 with Plug
Gross weight
107.2 Kilogram
Net weight
100.08 Kilogram
Volume
232.8 Liter
EAN
5702421555293
Approval standard
DIN EN 1092-2
China RoHS compliance
Out of scope
Connection size
200
Connection types
Flange
Contain batteries
No
Description
FVF DN200 PN16 with Plug
Diameter [mm]
200 mm
EU RoHS compliance
Out of scope
Kvs values [m³/h]
870 m³/h
Label product
Yes
Material
Grey cast iron EN-GJL-250 (GG25)
Media temperature [°C] [Max]
300 °C
Media temperature [°C] [Min]
-10 °C
Medium alternative
Glycolic water up to 50%
Mesh size [mm]
1.18 mm
Number of meshes [n/cm²]
25
Permissible media
District heating/cooling circulation water
Pressure class
PN 16
Pressure nominal [bar]
16 bar
Product group
Auxiliary Products
REACH Candidate List substances
No
Size
DN 200
Strainer type
With plug
Type
FVF
UK RoHS compliance
Out of scope
065B7821
Screens DN200 PN16-25 Normal+gasket
065B7835
Screens DN200 PN16-25 Fine+gasket
065B7798
FVF-M, Magnetic Insert DN200
065B7801
Drain ball valve FVF-B brass body, DN 65-300
065B7895
FVF gasket
