065B7759
Part Number: 065B7759
Product Information
Extended Description
065B7759 Danfoss: FVF DN50 PN16 with Plug, 2 holes, I-p
Gross weight
10.777 Kilogram
Net weight
9.1 Kilogram
Volume
18.667 Liter
EAN
5702421555699
Approval standard
DIN EN 1092-2
China RoHS compliance
Out of scope
Connection size
50
Connection types
Flange
Contain batteries
No
Description
FVF DN50 PN16 with Plug, 2 holes, I-p
Diameter [mm]
50 mm
EU RoHS compliance
Out of scope
Kvs values [m³/h]
54 m³/h
Material
Grey cast iron EN-GJL-250 (GG25)
Media temperature [°C] [Max]
300 °C
Media temperature [°C] [Min]
-10 °C
Medium alternative
Glycolic water up to 50%
Mesh size [mm]
0.87 mm
Number of meshes [n/cm²]
64
Permissible media
District heating/cooling circulation water
Pressure class
PN 16
Pressure nominal [bar]
16 bar
Product group
Auxiliary Products
REACH Candidate List substances
No
Size
DN 50
Strainer type
With plug
Type
FVF
UK RoHS compliance
Out of scope
FVF
FVF
Danfoss EU BF273686516767en-001001.06
Danfoss UK 220928EN0807101.01
FVF strainer with plug
FVF_DN15-300_PN16_RFA
Strainer - FVF - DN65 - 065B7745, 065B7746, 065B7747, 065B7748, 065B7775, 065B7776, 065B7777, 065B7778
Strainer - FVF - DN65 - 065B7745, 065B7746, 065B7747, 065B7748, 065B7775, 065B7776, 065B7777, 065B7778
FVF strainer with plug
