065B7763
Part Number: 065B7763
Product Information
Extended Description
065B7763 Danfoss: FVF DN50 PN16 Plug-Special Screen, I-p
Gross weight
10.638 Kilogram
Net weight
9 Kilogram
Volume
18.667 Liter
EAN
5702421555736
Approval standard
DIN EN 1092-2
China RoHS compliance
Out of scope
Connection size
50
Connection types
Flange
Contain batteries
No
Description
FVF DN50 PN16 Plug-Special Screen, I-p
Diameter [mm]
50 mm
EU RoHS compliance
Out of scope
Kvs values [mÂł/h]
49 mÂł/h
Material
Grey cast iron EN-GJL-250 (GG25)
Media temperature [°C] [Max]
300 °C
Media temperature [°C] [Min]
-10 °C
Medium alternative
Glycolic water up to 50%
Mesh size [mm]
0.4 mm
Number of meshes [n/cm²]
280
Permissible media
District heating/cooling circulation water
Pressure class
PN 16
Pressure nominal [bar]
16 bar
Product group
Auxiliary Products
REACH Candidate List substances
No
Size
DN 50
Strainer type
With plug
Type
FVF
UK RoHS compliance
Out of scope
065B7815
Screens DN50 PN16-25 Normal+gasket
065B7829
Screens DN50 PN16-25 Fine+gasket
065B7793
FVF-M, Magnetic Insert DN50
065B7889
FVF gasket
