065B7847
Part Number: 065B7847
Product Information
Extended Description
065B7847 Danfoss: FVF DN300 PN16 with Plug, 2 holes
Gross weight
280 Kilogram
Net weight
238 Kilogram
Volume
299.299 Liter
EAN
5702421556160
Approval standard
DIN EN 1092-2
China RoHS compliance
Out of scope
Connection size
300
Connection types
Flange
Contain batteries
No
Description
FVF DN300 PN16 with Plug, 2 holes
Diameter [mm]
300 mm
EU RoHS compliance
Out of scope
Kvs values [m³/h]
1735 m³/h
Material
Grey cast iron EN-GJL-250 (GG25)
Media temperature [°C] [Max]
300 °C
Media temperature [°C] [Min]
-10 °C
Medium alternative
Glycolic water up to 50%
Mesh size [mm]
1.18 mm
Number of meshes [n/cm²]
25
Permissible media
District heating/cooling circulation water
Pressure class
PN 16
Pressure nominal [bar]
16 bar
Product group
Auxiliary Products
REACH Candidate List substances
No
Size
DN 300
Strainer type
With plug
Type
FVF
UK RoHS compliance
Out of scope
