065F0115
Part Number: 065F0115
Product Information
Extended Description
065F0115 Danfoss: VMT PN10 15/1,5 2-way/8 ext.thr Straight
Gross weight
0.25 Kilogram
Net weight
0.246 Kilogram
Volume
0.447 Liter
EAN
5702420030357
Application
Heating and cooling
Cavitation factor
0.5
Connection size
G 3/4 A
Connection types
External Thread
Contain batteries
No
Description
VMT PN10 15/1,5 2-way/8 ext.thr Straight
Diameter [mm]
15 mm
Differential pressure range [bar] [Max]
0.8 bar
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(c)
Flow characteristic
Linear
Function
Control valve
Kvs values [mÂł/h]
1.5 mÂł/h
Media pH [Max]
10
Media pH [Min]
7
Media temperature [°C] [Max]
120 °C
Media temperature [°C] [Min]
2 °C
Medium alternative
Glycolic water up to 30%
Mounting version
Free
Number of ports
2
Permissible media
District heating/cooling circulation water
PN alternative VSP
6
Pressure class
PN 10
Pressure nominal [bar]
10 bar
Product group
Motorized control valves
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Spindle position
Normally open
Stroke [mm]
1.1 mm
Type
VMT
Valve body material
Brass W. No 2.0402
Valve cone material
NBR rubber
Valve size
DN 15
065F0006
Valve st.boxRAV,VMT/A/V,KOVM,AVD(S)A I-p
013G4125
Compression fittings for steel and copper tubings, G 3/4", 15, Nickel plated
013G4126
Compression fittings for steel and copper tubings, G 3/4", 16, Nickel plated
013G4128
Compression fittings for steel and copper tubings, G 3/4", 18, Nickel plated
065F0006
Valve st.boxRAV,VMT/A/V,KOVM,AVD(S)A I-p
Making applications future proof, all our knowledge – is now yours
Valve characteristics for motorized valves
Motorized Control Valves for district heating & cooling, heating and HVAC systems
Hydronic Specialties Controls Catalog and Application Guide
RAVI
VMT
VMT Valve Datasheet
VMT
Actuators pressure flow and temperature
2-way seated valve type VMT 2
VMT_DN15-8_Kvs1.5_3D
VMT_DN15-8_Kvs1.5_STEP
VMT_DN15-8_Kvs1.5_2D
