065Z0374
Part Number: 065Z0374
Product Information
Extended Description
065Z0374 Danfoss: VL2 PN6 DN15/2,5 flange
Gross weight
1.944 Kilogram
Net weight
1.944 Kilogram
Volume
6.879 Liter
EAN
5710104009261
Application
Heating and cooling
Application alternative VSP
District heating
Cavitation factor
0.4
Connection types
Flange
Contain batteries
No
Control ratio
50:1
Description
VL2 PN6 DN15/2,5 flange
Diameter [mm]
15 mm
Differential pressure range [bar] [Max]
4 bar
Flow characteristic
Equal percentage
Kvs values [m=C2=B3/h]
2.5 m=C2=B3/h
Leakage through port max. [% Kvs]
bubble tight design
Media pH [Max]
10
Media pH [Min]
7
Media temperature [=C2=B0C] [Max]
120 =C2=B0C
Media temperature [=C2=B0C] [Min]
-10 =C2=B0C
Medium alternative
Glycolic water up to 50%
Mounting version
Flow
Number of ports
2
Permissible media
District heating/cooling circulation water
Pressure nominal [bar]
6 bar
Product group
Other valves
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Stroke [mm]
10 mm
Stuffing box sealing material
EPDM
Type
VL 2
Valve body material
Grey cast iron EN-GJL-250 (GG-25)
Valve cone material
Brass
Valve stem material
Stainless steel
065Z0311
AdapAMx15/16/25/35-VRB/G,VF/L2009dn15-50
065Z0315
Stem heater for AMV(E) 335/435
065Z0321
Valve stuff.box VRB,VRG,VF,VL DN15 g200
VL2, VL3
VL (DN15-100)/VF (DN15-150) valves
Butterfly, other valves, Manual balancing valves, one pipe solution valves and hot water balancing valves
Danfoss MD BF11032024-en01.01
2-way seated valve type VL 2
VL2_DN15_
2-way seated valve VL 2
2-way seated valve VL 2
VL2_DN15_STEP
VL2_DN15_2D
VL2_DN15-DN100_AMV(E) 25(35)_RFA
VL2_DN15-DN100_AMV(E) 435_RFA
VL2_DN15-DN100_AMV(E) 438 SU_RFA
VL2_DN15-DN100_RFA
