067B2512
Part Number: 067B2512
Product Information
Extended Description
067B2512 Danfoss: Temperature range [=C2=B0C]: -40 - 10, Pressure equalization: Externally equalized
Gross weight
0.634 Kilogram
Net weight
0.495 Kilogram
Volume
2.12 Liter
EAN
5702428998529
Approval
EAC,LLC CDC TYSK
Body material
Brass
Capillary tube length [in]
118 in
Capillary tube length [mm]
3000 mm
China RoHS compliance
Yes
Contain batteries
No
Equalization connection type
Flare
Equalization size [in]
1/4 in
EU RoHS compliance
Out of scope
Max. Working Pressure [bar]
28 bar
Max. Working Pressure [psig]
400 psig
Packing format
Multi pack
Parts Program name
TE 12
Pressure equalization
Externally equalized
Product group
Expansion valves
Product Name Description
Element for expansion valve
Quantity per packing format
9 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Refrigerants
R448A,R449A
SCIP dossier no.
7a4717a2-7803-4273-9d94-59ccfb927c1e
SCIP dossier product name
TE
Temperature range [=C2=B0C] [max]
10 =C2=B0C
Temperature range [=C2=B0C] [min]
-40 =C2=B0C
Temperature range [=C2=B0F] [max]
50 =C2=B0F
Temperature range [=C2=B0F] [min]
-40 =C2=B0F
Type
TE 12
Type designation
Element
068B0676
Generic accessories, Accessory bag, Seal kit
067N0557
Generic accessories, Accessory bag bulb strap L225mm I/40
