070L3482
Part Number: 070L3482
Product Information
Extended Description
070L3482 Danfoss: RSA 95
Gross weight
2.564 Kilogram
Net weight
2.431 Kilogram
Volume
3.37 Liter
EAN
5702425002120
ROTATION
L
1 or 2 stage
1
Ambient temperature [°C] [max]
120 °C
Ambient temperature [°C] [min]
-20 °C
Approval
CE
Biofuel blend
100
Capacity [l/h]
180 L/h
Capacity group
150-299
Capacity range [l/h] [Max]
299 L/h
Capacity range [l/h] [Min]
150 L/h
CE evaluated
Yes
China RoHS compliance
Out of scope
Closing function
Shut-off
Comments
Rotation and nozzle/pressure outlet are always determined viewing from the shaft end of the pump.
Contain batteries
No
Definition point [l/h]
2800 min-1, 10 bar, 4.3 cSt
Description
RSA 95
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(a),6(c)
Factory pressure setting [bar]
10 bar
Filter area [cm²]
170 cm²
Filter grade [µm]
150
Filter type
Ring
Flats/key on the shaft
1 flat
Media temperature [°C] [Max]
120 °C
Media temperature [°C] [Min]
-10 °C
Nozzle/pressure outlet
L
Number of stages
1
Oil pump speed [op/min]
3600 op/min
Oil type
Kerosene/Light oil
Packing format
Multi pack
Pipe connection
2 pipes
Power consumption [W]
161 W
Pressure [bar] [Max]
21 bar
Pressure [bar] [Min]
5.5 bar
Pressure feed line [bar] [Max]
4 bar
Pressure kerosene [bar] [Max]
12 bar
Pressure range special spring [bar] [Max]
5 bar
Pressure range special spring [bar] [Min]
1 bar
Product group
Pumps
Quantity per packing format
6 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
SCIP dossier no.
f8b515ca-d436-41cf-83c4-a1485267071b
SCIP dossier product name
Oil pumps - RSA 095
Serie
RS
Shaft Diameter [in]
7/16
Speed [rpm] [Max]
3600 rpm
Speed [rpm] [Min]
1400 rpm
Starting torque [Nm] [Max]
0.3 N-m
Storage temperature [°C] [Max]
120 °C
Storage temperature [°C] [Min]
-25 °C
Suction Line Vacuum [bar] [Max]
0.4 bar
Type
RSA
UK RoHS compliance
Yes with exemptions
UK RoHS exemption clause
12,18
UL evaluated
Out of scope
Viscosity [cSt] [Max]
18 cSt
Viscosity [cSt] [Min]
1.3 cSt
070-0031
HIGH PRESSURE SPRING 15-30 Bar.
070-0032
STRAINER SET RSA28/40/60
070-0033
STRAINER SET RSA95/125
070-0030
LOW PRESSURE SPRING 1-5 Bar.
070-0033
STRAINER SET RSA95/125
070-0211
FLANGE
070-0020
2-PIPE SCREW
