071N0109
Part Number: 071N0109
Product Information
Extended Description
071N0109 Danfoss: BFP 21R3R
Gross weight
1.152 Kilogram
Net weight
1.032 Kilogram
EAN
5702425015014
ROTATION
R
1 or 2 stage
1
Actuator type
NC
Ambient temperature [°C] [max]
70 °C
Ambient temperature [°C] [min]
-20 °C
Approval
CE,UKCA,Intertek Semko,DIN CERTCO
Biofuel blend
10
Capacity [l/h]
24 L/h
Capacity group
0-24
Capacity range [l/h] [Max]
24 L/h
Capacity range [l/h] [Min]
0 L/h
CE evaluated
Yes
China RoHS compliance
Out of scope
Closing function
Cut-off
Coil consumption [W]
9 W
Coil Current
AC
Coil voltage [V]
220 - 230
Comments
Rotation and nozzle/pressure outlet are always determined viewing from the shaft end of the pump.
Contain batteries
No
Definition point [l/h]
2800 min-1, 10 bar, 4.3 cSt
Description
BFP 21R3R
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(a)-I,6(c)
Factory pressure setting [bar]
10 bar
Filter area [cm²]
11 cm²
Filter grade [µm]
200
Filter type
Cartridge
Flats/key on the shaft
1 flat
Grade of enclosure
IP40
Media temperature [°C] [Max]
70 °C
Media temperature [°C] [Min]
0 °C
Nozzle/pressure outlet
R
Number of stages
1
Oil pump speed [op/min]
3450 op/min
Oil type
Kerosene/Light oil
Packing format
Pallet pack
Pipe connection
2 pipes
Power consumption [W]
42 W
Pressure [bar] [Max]
20 bar
Pressure [bar] [Min]
7 bar
Pressure feed line [bar] [Max]
2 bar
Pressure kerosene [bar] [Max]
12 bar
Product group
Pumps
Quantity per packing format
500 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
SCIP dossier no.
f7a3d9f5-c783-43a4-84ec-d54732783baf
SCIP dossier product name
Oil pump BFP 21
Serie
BFP
Shaft diameter [mm]
8 mm
Speed [rpm] [Max]
3450 rpm
Speed [rpm] [Min]
2400 rpm
Starting torque [Nm] [Max]
0.1 N-m
Storage temperature [°C] [Max]
70 °C
Storage temperature [°C] [Min]
-20 °C
Suction Line Vacuum [bar] [Max]
0.4 bar
Supply peak voltage [V] [Max]
253 V
Supply peak voltage [V] [Min]
207 V
Supply voltage [V]
230 V
Supply voltage [V] [Max]
240 V
Supply voltage [V] [Min]
220 V
Type
BFP 21
UK RoHS compliance
Yes with exemptions
UK RoHS exemption clause
13,18
UL evaluated
Out of scope
Viscosity [cSt] [Max]
12 cSt
Viscosity [cSt] [Min]
1.3 cSt
071N0061
COIL 110/120 V AC.
071G2245
CABLE FOR NC VALVE, 2100 mm
071G0200
CABLE FOR NC VALVE, 500 mm OEM
071N0065
PLUG M10 FOR NC VALVE.
071G0202
CABLE FOR NC VALVE, 280 mm OEM
071N0007
NC SERVICE VALVE FOR 24 V DC
071N0062
Coil 24 V AC.
071B0011
BUSH 32 → 54 mm.
071N0074
PLUG FOR CARTRIGDE FILTER.
071N1033
O-rings for cover (ø54) and regulator (ø9,75)
