071N0213
Part Number: 071N0213
Product Information
Extended Description
071N0213 Danfoss: BFP 11L3L
Gross weight
1.111 Kilogram
Net weight
1.11 Kilogram
Volume
1.203 Liter
EAN
5702425026997
ROTATION
L
1 or 2 stage
1
Actuator type
NC
Ambient temperature [°C] [max]
70 °C
Ambient temperature [°C] [min]
-20 °C
Approval
CE,UKCA,Intertek Semko,DIN CERTCO
Biofuel blend
10
Capacity [l/h]
24 L/h
Capacity group
0-24
Capacity range [l/h] [Max]
24 L/h
Capacity range [l/h] [Min]
0 L/h
CE evaluated
Yes
China RoHS compliance
Out of scope
Closing function
Cut-off
Coil consumption [W]
9 W
Coil Current
AC
Coil voltage [V]
220 - 230
Comments
Rotation and nozzle/pressure outlet are always determined viewing from the shaft end of the pump.
Contain batteries
No
Definition point [l/h]
2800 min-1, 10 bar, 4.3 cSt
Description
BFP 11L3L
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(a)-I,6(c)
Factory pressure setting [bar]
12 bar
Filter area [cm²]
13 cm²
Filter grade [µm]
200
Filter type
Ring
Flats/key on the shaft
1 flat
Grade of enclosure
IP40
Media temperature [°C] [Max]
70 °C
Media temperature [°C] [Min]
0 °C
Nozzle/pressure outlet
L
Number of stages
1
Oil pump speed [op/min]
3450 op/min
Oil type
Kerosene/Light oil
Packing format
Industrial pack
Pipe connection
1 pipe
Power consumption [W]
42 W
Pressure [bar] [Max]
15 bar
Pressure [bar] [Min]
7 bar
Pressure feed line [bar] [Max]
2 bar
Pressure kerosene [bar] [Max]
12 bar
Product group
Pumps
Quantity per packing format
10 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
SCIP dossier no.
b1c30c39-2a01-4a7e-aa0f-69a47ec00790
SCIP dossier product name
Oil pump BFP 11
Serie
BFP
Shaft diameter [mm]
8 mm
Speed [rpm] [Max]
3450 rpm
Speed [rpm] [Min]
2400 rpm
Starting torque [Nm] [Max]
0.1 N-m
Storage temperature [°C] [Max]
70 °C
Storage temperature [°C] [Min]
-20 °C
Suction Line Vacuum [bar] [Max]
0.4 bar
Supply peak voltage [V] [Max]
253 V
Supply peak voltage [V] [Min]
207 V
Supply voltage [V]
230 V
Supply voltage [V] [Max]
240 V
Supply voltage [V] [Min]
220 V
Type
BFP 11
UK RoHS compliance
Yes with exemptions
UK RoHS exemption clause
12,18
UL evaluated
Out of scope
Viscosity [cSt] [Max]
12 cSt
Viscosity [cSt] [Min]
1.3 cSt
071G0200
CABLE FOR NC VALVE, 500 mm OEM
071G0204
CABLE FOR NC VALVE, 710 mm OEM
071G2245
CABLE FOR NC VALVE, 2100 mm
071N0007
NC SERVICE VALVE FOR 24 V DC
071N0047
BUSH 32 → 54 mm W. STD. FLANGE.
071N1033
O-rings for cover (ø54) and regulator (ø9,75)
071N0050
NC VALVE
071G0202
CABLE FOR NC VALVE, 280 mm OEM
071N1055
PLUG FOR 1/4" CONNECTIONS
071N0061
COIL 110/120 V AC.
