071N0258
Part Number: 071N0258
Product Information
Extended Description
071N0258 Danfoss: BFP 21L5 L+R
Gross weight
1.109 Kilogram
Net weight
1.07 Kilogram
Volume
1.518 Liter
EAN
5702425023835
ROTATION
L
1 or 2 stage
1
Actuator type
NC
Ambient temperature [°C] [max]
70 °C
Ambient temperature [°C] [min]
-20 °C
Approval
CE,UKCA,DIN CERTCO,Intertek Semko
Biofuel blend
10
Capacity [l/h]
42 L/h
Capacity group
25-49
Capacity range [l/h] [Max]
49 L/h
Capacity range [l/h] [Min]
25 L/h
CE evaluated
Yes
China RoHS compliance
Out of scope
Closing function
Cut-off
Coil consumption [W]
9 W
Coil Current
AC
Coil voltage [V]
220 - 230
Comments
Rotation and nozzle/pressure outlet are always determined viewing from the shaft end of the pump.
Contain batteries
No
Definition point [l/h]
2800 min-1, 10 bar, 4.3 cSt
Description
BFP 21L5 L+R
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(a)-I,6(c)
Factory pressure setting [bar]
10 bar
Filter area [cm²]
11 cm²
Filter grade [µm]
200
Filter type
Cartridge
Flats/key on the shaft
1 flat
Grade of enclosure
IP40
Media temperature [°C] [Max]
70 °C
Media temperature [°C] [Min]
0 °C
Nozzle/pressure outlet
L + R
Number of stages
1
Oil pump speed [op/min]
3450 op/min
Oil type
Kerosene/Light oil
Packing format
Industrial pack
Pipe connection
2 pipes
Power consumption [W]
70 W
Pressure [bar] [Max]
20 bar
Pressure [bar] [Min]
7 bar
Pressure feed line [bar] [Max]
2 bar
Pressure kerosene [bar] [Max]
12 bar
Product group
Pumps
Quantity per packing format
10 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
SCIP dossier no.
f7a3d9f5-c783-43a4-84ec-d54732783baf
SCIP dossier product name
Oil pump BFP 21
Serie
BFP
Shaft diameter [mm]
8 mm
Speed [rpm] [Max]
3450 rpm
Speed [rpm] [Min]
1400 rpm
Starting torque [Nm] [Max]
0.12 N-m
Storage temperature [°C] [Max]
70 °C
Storage temperature [°C] [Min]
-20 °C
Suction Line Vacuum [bar] [Max]
0.4 bar
Supply peak voltage [V] [Max]
253 V
Supply peak voltage [V] [Min]
207 V
Supply voltage [V]
230 V
Supply voltage [V] [Max]
240 V
Supply voltage [V] [Min]
220 V
Type
BFP 21
UK RoHS compliance
Yes with exemptions
UK RoHS exemption clause
12,18
UL evaluated
Out of scope
Viscosity [cSt] [Max]
12 cSt
Viscosity [cSt] [Min]
1.3 cSt
071G0202
CABLE FOR NC VALVE, 280 mm OEM
071N0062
Coil 24 V AC.
071G2245
CABLE FOR NC VALVE, 2100 mm
071N0074
PLUG FOR CARTRIGDE FILTER.
071N1033
O-rings for cover (ø54) and regulator (ø9,75)
071N0050
NC VALVE
071N0007
NC SERVICE VALVE FOR 24 V DC
071B0011
BUSH 32 → 54 mm.
071N0065
PLUG M10 FOR NC VALVE.
071N0047
BUSH 32 → 54 mm W. STD. FLANGE.
