080G0320
Part Number: 080G0320
Product Information
Extended Description
080G0320 Danfoss: Function: CO2 Pack, Digital inputs (DI) [pc]: 8, Supply voltage [V] AC: 24, Communication type: MODBUS, Packing format: Multi pack, Quantity per packing format: 12
Gross weight
0.662 Kilogram
Net weight
0.629 Kilogram
Volume
2.837 Liter
EAN
5702428587259
1 Primary battery SUM weight Kg
0.001
1 Primary battery weight Kg
0.001
Analog inputs (AI) [pc]
8 pc
Analog outputs (AO) [pc]
3 pc
Application area
Capacity control
Approval
CE,CMIM,EAC,cURus
Battery qty
1
Battery type or Name
Lithium coin cell
Capacity control input
Pressure/ Temperature
Capacity control mode
PI
CE evaluated
Yes
China RoHS compliance
Out of scope
Communication type
MODBUS
Compressor capacity mode
Step/ Speed/ PWM
Condenser control type
Pressure/ Temperature
Contain batteries
Yes
Digital inputs (DI) [pc]
8 pc
Digital outputs (DO) [pc]
8 pc
Display - option
On front. Option: MMIGRS2
Display on front
Yes
Equipment
Incl. Connectors
EU RoHS compliance
Out of scope
Fan capacity control
Speed
Fan control mode
PI
Frequency [Hz]
50/60 Hz
Function
CO2 Pack
Further information
Relays 5,6 solid state type
Mounting method
DIN rail
Number of Compressors max.
5 pc
Packing format
Multi pack
Power consumption [W]
10 W
Product accessories
Electron. control accessories
Product features
CO2 compliant,Compressor safety,Discharge gas temp. safety,Fan safety,Floating condenser pressure,Heat recovery function,High pressure safety,LCD display built in,Load shedding,Low pressure safety,Night optimization,P0 optimization,Receiver pressure control,Suction gas temp. safety
Product group
Compressor/condenser control
Product Language
Croatian,Czech,Danish,Dutch,English,French,German,Hungarian,Italian,Polish,Portuguese,Romania,Russian,Serbian,Spanish,Turkish
Product Name Description
Pack controller
Quantity per packing format
12 pc
Serviceable
No
Supply voltage [V] AC
24 V
Supply voltage [V] DC
24 V
Type
AK-PC 572
Type designation
AK-PC 572
UK RoHS compliance
Out of scope
UL evaluated
Yes
080G0075
Electron. control accessories, ACCCBI Cable, U.I. 1.5m, MCX series
080G0076
Electron. control accessories, ACCCBI Cable Telephone U.I. 3m, MCX series
080G0294
Control panel, MMIGRS2
080G0325
Stepper valve driver, EKE 1P
080G5555
Backup power module, EKE 2U
Overview brochure: Pack Controllers
AK-PC 572
UK PSTI regulation for Pack Controllers and Extension Modules
CO2 Minipack Solution
Capacity Controller for CO2 mini pack AK-PC 572
Danfoss EU-UK 080R1226.02
Pack controllers (Mid End)
Danfoss MD 080R1221.02
AK-PC 572 Pack controller
ak_pc 572 080G0320 _ STP
ak_pc 572 080G0320 _ JPG
ak_pc 572 080G0320 _ JPG
ak_pc 572 080G0320 _ JPG
