080G6012
Part Number: 080G6012
Product Information
Extended Description
080G6012 Danfoss: Function: I/O module, Packing format: Single pack, Quantity per packing format: 1
Gross weight
0.28 Kilogram
Net weight
0.17 Kilogram
Volume
1.152 Liter
EAN
5715162703359
Analog inputs (AI) [pc]
10 pc
Analog outputs (AO) [pc]
2 pc
Application area
Programmable controller
Approval
CE,UL Recognized
Battery back-up [V] DC [max]
42 V
Battery back-up [V] DC [min]
18 V
Buzzer
No
CE evaluated
Yes
Connector kit Code No.
080G6026
Connector kit included
Yes
Control of Stepper driver [pc]
1 pc
Digital inputs (DI) [pc]
10 pc
Digital outputs (DO) [pc]
5 pc
Enclosure rating IP
IP20
Function
I/O module
Mounting method
DIN rail
Packing format
Single pack
Power consumption [W]
5 W
Product group
Programmable controllers
Product Name Description
I/O module
Quantity per packing format
1 pc
Real time clock
No
Serviceable
No
Type
AS-XP05+
Type designation
AS-XP05+ S
UL evaluated
Yes
080G6000
Program. controller, 6 relays, AS-CX06 Pro+
080G6006
Program. controller, 6 relays, AS-CX06 Mid
080G6002
Program. controller, 6 relays, AS-CX06 Pro
080G6004
Program. controller, 6 relays, AS-CX06 Mid+
Alsmart™ universal controller platform, type AS-XP05, AS-XP10, AS-PS20
ALSMART programmable controllers
Manufacturers declaration 080R6019
080G6012_as-xp05+
080G6012_as-xp05+
080G6012_as-xp05+
080G6012_as-xp05+
assembly_as-xp05p_ext.stp
assy_as-cx06-dy_xp10_ps20_xp05_ext.stp
assembly_as-cx06-dy_xp05p_drj_ext.stp
assembly_as-cx06_xp05p_ext.stp
assy_as-cx06-dy_xp05p_ps20_xp05p_ext.stp
