080Z0106
Part Number: 080Z0106
Product Information
Extended Description
080Z0106 Danfoss: Function: Fixed IO connections, Supply voltage [V] AC: 24, Communication type: RS232; LON RS485, Packing format: Single pack, Quantity per packing format: 1
Gross weight
0.932 Kilogram
Net weight
0.645 Kilogram
Volume
6.248 Liter
EAN
5702423287048
Analog inputs (AI) [pc]
11 pc
Application area
Capacity control
Approval
C-TICK,CE,EAC,LLC CDC TYSK,cURus
CE evaluated
Yes
China RoHS compliance
Out of scope
Communication type
LON RS485,RS232
Controller type
Pack Controller
Digital outputs (DO) [pc]
8 pc
Display - option
EKA 163B,EKA 164B,EKA 166
Display on front
No
EU RoHS compliance
Out of scope
Frequency [Hz]
50/60 Hz
Function
Fixed IO connections
Further information
Speed, Step
Number of Compressors max.
6 pc
Other RoHS documentation
EAEU RoHS
Packing format
Single pack
Power consumption [VA]
8 VA
Product accessories
Electron. control accessories
Product group
Compressor/condenser control
Product Language
Dutch,English,French,German,Italian,Spanish
Product Name Description
Pack controller
Quantity per packing format
1 pc
REACH Candidate List substances
No
Serviceable
No
Supply voltage [V] AC
24 V
Supply voltage [V] DC
24 V
Type
AK-PC 710
UK RoHS compliance
Out of scope
UL evaluated
Yes
