080Z5003

Part Number: 080Z5003
080Z5003
Manufacturer
Danfoss
Part number
080Z5003
Category

Product Information

Extended Description

080Z5003 Danfoss: Function: Management of cold rooms, Supply voltage [V] AC: 230, Communication type: RS485 Modbus, Packing format: Single pack, Quantity per packing format: 1
Gross weight
1.342 Kilogram
Net weight
1.024 Kilogram
Volume
6.518 Liter
EAN
5715162444221
Application area
Condensing Unit
Approval
CE,RoHS
CE evaluated
Yes
China RoHS compliance
Out of scope
Communication type
RS485 Modbus
Controller type
Optyma Control. 1phase (2HP)
Display - option
Yes
Enclosure rating IP
IP65
Frequency [Hz]
50/60 Hz
Function
Management of cold rooms
Packing format
Single pack
Power consumption [VA]
6.3 VA
Product group
Evaporator and room control
Product Name Description
Cold storage room controller
Quantity per packing format
1 pc
Supply voltage [V] AC
230 V
Type
AK-RC 305W-SD
Valve output type
(TXV)
Electronic Controls catalogue for comref Optyma controller, type AK-RC 204B, 205C, 305W-SD Optyma™ control AK-RC Single Phase mounting kit Temperature controller for walk-in coolers and freezers, type AK-RC 305W-SD Modbus parameters list, AK-RC 305W-SD CO2 solutions for small commercial cold rooms Temperature controller for walk-in coolers and freezers, type AK-RC 305W-SD Danfoss EU-UK 080R1239.00 Cold room controllers AK-RC 305W-SD, 080Z5003 Wiring diagram, type AK-RC 305W-SD Temperature controller for walk-in coolers and freezers, type AK-RC 305W-SD AK-RC 305W-SD & AK-RC 204B: Enclosure dimensions
