082H0221
Part Number: 082H0221
Product Information
Extended Description
082H0221 Danfoss: AMB 162 5Nm 3p 30s 230V
Gross weight
0.674 Kilogram
Net weight
0.643 Kilogram
Volume
1.991 Liter
EAN
5710104077741
Actuator speed [s/°]
30 s/°
Actuator type
Electrical
Ambient temperature [°C] [max]
50 °C
Ambient temperature [°C] [min]
0 °C
Application
temperature control in central heating
China RoHS compliance
Out of scope
Contain batteries
No
Control signal type
3-point
Description
AMB 162 5Nm 3p 30s 230V
Frequency [Hz]
50/60
Grade of enclosure
IP42
Manual operation
Yes
Operating torque [Nm]
5 N-m
Power consumption [W]
3 W
Product group
Gear actuators
Protection Class of the Coating
II
REACH Candidate List substances
No
Rotation angle [°]
90 °
Safety function
No
Speed type
Standard
Spindle speed [s/mm]
30 s/mm
Spring down (return)
No
Spring up
No
Storage temperature [°C] [Max]
80 °C
Storage temperature [°C] [Min]
-10 °C
Supply voltage [V] AC
230 V
Type
AMB 162
UK RoHS compliance
Out of scope
082H0250
AMB Linkage kit multi type
082H0251
AMB Linkage kit for Centra
082H0252
AMB Linkage kit for Wita, Meibes
082H0253
AMB Linkage kit for Honeywell
082H0254
AMB Linkage kit for ESBE VRG, Danfoss RV
082H0255
AMB Linkage kit for Danfoss HRB,HRE,HFE
Infographic - Actuator selection for AB-QM PICVs
AB-QM™ Interactive Quick Select Guide
AMB 162 /182
Danfoss EU 220621EN0802102.01
Gear and Thermal actuators
Electrical actuator type AMB 182 for rotary valves
HRE3_DN20-50_AMB 162(182)_RFA
HRB4_DN15-50_AMB 162(182)_RFA
AMB 162(182)_RFA
HRE4_DN20-50_AMB 162(182)_RFA
HFE3_DN20-150_AMB 162(182)_RFA
HRB3_DN15-50_AMB 162(182)_RFA
AMB 162(182)_STEP
AMB 162(182)_3D
AMB 162(182)_2D
