082H0224
Part Number: 082H0224
Product Information
Extended Description
082H0224 Danfoss: AMB 162 5Nm 3p 480s 230V
Gross weight
0.628 Kilogram
Net weight
0.628 Kilogram
Volume
2 Liter
EAN
5710104077802
Actuator speed [s/°]
480 s/°
Actuator type
Electrical
Ambient temperature [°C] [max]
50 °C
Ambient temperature [°C] [min]
0 °C
Application
temperature control in central heating
China RoHS compliance
Out of scope
Contain batteries
No
Control signal type
3-point
Description
AMB 162 5Nm 3p 480s 230V
Frequency [Hz]
50/60
Grade of enclosure
IP42
Manual operation
Yes
Operating torque [Nm]
5 N-m
Power consumption [W]
3 W
Product group
Gear actuators
Protection Class of the Coating
II
REACH Candidate List substances
No
Rotation angle [°]
90 °
Safety function
No
Speed type
Standard
Spindle speed [s/mm]
480 s/mm
Spring down (return)
No
Spring up
No
Storage temperature [°C] [Max]
80 °C
Storage temperature [°C] [Min]
-10 °C
Supply voltage [V] AC
230 V
Type
AMB 162
UK RoHS compliance
Out of scope
082H0250
AMB Linkage kit multi type
082H0251
AMB Linkage kit for Centra
082H0252
AMB Linkage kit for Wita, Meibes
082H0253
AMB Linkage kit for Honeywell
082H0254
AMB Linkage kit for ESBE VRG, Danfoss RV
082H0255
AMB Linkage kit for Danfoss HRB,HRE,HFE
