082H0226

Part Number: 082H0226
082H0226
Manufacturer
Danfoss
Part number
082H0226
Category

Product Information

Extended Description

082H0226 Danfoss: AMB 162 5Nm 3p 30s 230V AS
Gross weight
0.71 Kilogram
Net weight
0.697 Kilogram
Volume
2.007 Liter
EAN
5710104077840
Actuator speed [s/°]
30 s/°
Actuator type
Electrical
Ambient temperature [°C] [max]
50 °C
Ambient temperature [°C] [min]
0 °C
Application
temperature control in central heating
China RoHS compliance
Out of scope
Contain batteries
No
Control signal type
3-point
Description
AMB 162 5Nm 3p 30s 230V AS
Frequency [Hz]
50/60
Grade of enclosure
IP42
Manual operation
Yes
Operating torque [Nm]
5 N-m
Power consumption [W]
3 W
Product group
Gear actuators
Protection Class of the Coating
II
REACH Candidate List substances
No
Rotation angle [°]
90 °
Safety function
No
Speed type
Standard
Spindle speed [s/mm]
30 s/mm
Spring down (return)
No
Spring up
No
Storage temperature [°C] [Max]
80 °C
Storage temperature [°C] [Min]
-10 °C
Supply voltage [V] AC
230 V
Type
AMB 162
UK RoHS compliance
Out of scope
082H0250
AMB Linkage kit multi type
082H0251
AMB Linkage kit for Centra
082H0252
AMB Linkage kit for Wita, Meibes
082H0253
AMB Linkage kit for Honeywell
082H0254
AMB Linkage kit for ESBE VRG, Danfoss RV
082H0255
AMB Linkage kit for Danfoss HRB,HRE,HFE
Infographic - Actuator selection for AB-QM PICVs AB-QM™ Interactive Quick Select Guide AMB 162 /182 Danfoss EU 220621EN0802102.01 Gear and Thermal actuators Electrical actuator type AMB 182 for rotary valves HRE3_DN20-50_AMB 162(182)_RFA HRB4_DN15-50_AMB 162(182)_RFA AMB 162(182)_RFA HRE4_DN20-50_AMB 162(182)_RFA HFE3_DN20-150_AMB 162(182)_RFA HRB3_DN15-50_AMB 162(182)_RFA AMB 162(182)_STEP AMB 162(182)_3D AMB 162(182)_2D
