084B4664
Part Number: 084B4664
Product Information
Extended Description
084B4664 Danfoss: Function: Comp.,Defrost,Fan,Alarm,More f, Controller type: Refrig. Controller (Temp), Communication type: RS485; MODBUS, Packing format: Industrial pack, Quantity per packing format: 9
Gross weight
0.383 Kilogram
Net weight
0.317 Kilogram
Volume
1.25 Liter
EAN
5702428890335
Analog inputs (AI) [pc]
3 pc
Application area
Temperature control
Approval
C-TICK,CE,EAC,CMIM
CE evaluated
Yes
China RoHS compliance
Out of scope
Communication type
MODBUS,RS485
Controller type
Refrig. Controller (Temp)
Digital inputs (DI) [pc]
2 pc
Digital outputs (DO) [pc]
4 pc
Display - option
EKA 163A,EKA 164A
Display on front
Yes
EU RoHS compliance
Out of scope
Frequency [Hz]
50/60 Hz
Function
Comp.,Defrost,Fan,Alarm,More f
Further information
Alarm= Light or Railheat
Identical product
084B4164
Number of Compressors max.
1 pc
Number of Evaporators max.
1 pc
Number of Sensor inputs
3 pc
Other RoHS documentation
EAEU RoHS
Packing format
Industrial pack
Power consumption [VA]
2.3 VA
Product accessories
Electron. control accessories
Product group
Evaporator and room control
Product Language
English
Product Name Description
Refrig appliance control (TXV)
Quantity per packing format
9 pc
REACH Candidate List substances
No
Sensor type
Temp.Sensors
Serviceable
No
Supply voltage [V] AC
230 V
Temp. sensor support
NTC-M2020,PTC 1000,Pt 1000
Type
EKC 302D
UK RoHS compliance
Out of scope
Valve output type
EVR (TXV)
Detailed overview of ADAP-KOOL™ Case Controllers
EKC 202D - EKC 302D
Controller for temperature control EKC 202D - EKC 302D
Danfoss EU-UK 084R0835.AB
UL E31024
Refrigeration appliance control (TXV)
Danfoss MD 080R0815.02
Danfoss MD 080R1205.01
Danfoss MD 080R1221.02
Danfoss MD-UK 080R1228.04
EKC 302
