084H5002
Part Number: 084H5002
Product Information
Extended Description
084H5002 Danfoss: Air purgers, Parts included: Bolts for flange; Welding flange; Gasket; Screws for top cover, Refrigerants: R717
Gross weight
114 Kilogram
Net weight
100 Kilogram
Volume
691.2 Liter
EAN
5714279888126
Ambient temperature range [°C] [max]
43 °C
Ambient temperature range [°C] [min]
-10 °C
Approval
CE
CE evaluated
Yes
China RoHS compliance
Out of scope
Connection size [in]
1 1/4 in
Connection size [mm]
32 mm
Connection standard
FLANGE, DIN-EN OR ANSI
Connection type
Butt weld
Contain batteries
No
Enclosure rating IP
IP55
EU RoHS compliance
Out of scope
Frequency [Hz]
60 Hz
Max. purger electr conn points
8
Max. Working Pressure [bar]
40 bar
Packing format
Single pack
Parts included
Bolts for flange,Gasket,Screws for top cover,Welding flange
Product accessories
Air purger accessories
Product group
Air purgers
Product Language
English
Product Name Description
Intelligent purging system
Product version
01
Quantity per packing format
1 pc
Refrigerants
R717
Serviceable
Air purger spare parts
Software version
4.13
Supply voltage [V] AC
230 V
Type
IPS 8
UK RoHS compliance
Out of scope
