084Z3012

Part Number: 084Z3012
084Z3012
Manufacturer
Danfoss
Part number
084Z3012
Category

Product Information

Extended Description

084Z3012 Danfoss: Electrical connection: Cable, Cable type: Teflon
Gross weight
0.256 Kilogram
Net weight
0.243 Kilogram
Volume
0.95 Liter
EAN
5702423209910
Cable length [in]
236 in
Cable length [m]
6 m
Cable tempr. range [=C2=B0C] [max]
200 =C2=B0C
Cable tempr. range [=C2=B0C] [min]
-80 =C2=B0C
Cable tempr. range [=C2=B0F] [max]
392 =C2=B0F
Cable tempr. range [=C2=B0F] [min]
-112 =C2=B0F
Cable type
Teflon
CE evaluated
Yes
China RoHS compliance
Yes exceed limitations
Contain batteries
No
EEE category
5 small equipment (any external dimension 50 cm)
Electrical connection
Cable
Electrical connection size
4 wire
Enclosure rating IP
IP68
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(a),6(b),6(c),7(a),7(c)-I
In scope of WEEE
Yes
Insertion type
Variable
Output signal
Ohm
Packing format
Multi pack
Product group
Sensors
Product Name Description
Temperature sensor
Protection tube diameter [in]
0.236 in
Protection tube diameter [mm]
6 mm
Protection tube material
AISI 305
Quantity per packing format
8 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
SCIP dossier no.
fdf4160e-1955-41c0-8584-16b48c4e3655
Sensor elem. resistance [Ohm]
1000
Sensor element [pc]
2 pc
Sensor element standard
EN 60751
Sensor element tolerance
Class B
Sensor element type
Pt
Temperature range [=C2=B0C] [max]
200 =C2=B0C
Temperature range [=C2=B0C] [min]
-50 =C2=B0C
Temperature range [=C2=B0F] [max]
392 =C2=B0F
Temperature range [=C2=B0F] [min]
-58 =C2=B0F
Type
MBT 153
Type designation
MBT 153-4300-0600
UK RoHS compliance
Out of scope
Wires [pcs]
2 pc
084N2045
Sensor pocket, AKS 120, NPT
084Z2431
Sensor pocket, MBT 120
084N2040
Sensor pocket, AKS 120
084Z2324
Sensor pocket, MBT 120
084Z2325
Sensor pocket, MBT 120
084Z6052
Sensor pocket, MBT 120
084Z6053
Sensor pocket, MBT 120
084Z6054
Sensor pocket, MBT 120
Temperature sensor overview for wholesaler Temperature sensor, type MBT 153 and MBT 120 AKS 12 and MBT 153 change of beading process Temperature sensor overview for wholesaler Danfoss EU-UK 084R1019.04 DEMKO 12CA69359 Pressure & Temperature Sensors Danfoss MD 084R1022.01 Danfoss MD 087R0017.01 DNV GL TAA000006F Rev. 3 MBT 153 Temperature sensor, Cable, teflon
