084Z3028

Part Number: 084Z3028
084Z3028
Manufacturer
Danfoss
Part number
084Z3028
Category

Product Information

Extended Description

084Z3028 Danfoss: Temperature range [=C2=B0C]: -50 - 200, Sensor element type: Pt, Sensor elem. resistance [Ohm]: 100, Protection tube material: AISI 316 Ti, Electrical connection: Type B, Electrical connection size: M16 x 1.5
Gross weight
0.378 Kilogram
Net weight
0.367 Kilogram
Volume
0.99 Liter
EAN
5702423212491
Ambient temperature max. [=C2=B0C]
90 =C2=B0C
Ambient temperature max. [=C2=B0F]
194 =C2=B0F
CE evaluated
Yes
China RoHS compliance
Yes exceed limitations
Connection material
Stainless steel
Connection standard
ISO 228
Connection type
G
Contain batteries
No
EEE category
5 small equipment (any external dimension 50 cm)
Electrical connection
Type B
Electrical connection size
M16 x 1.5
Enclosure rating IP
IP65
EU RoHS compliance
Yes with exemptions
EU RoHS exemption clause
6(a),6(b),6(c),7(a),7(c)-I
In scope of WEEE
Yes
Insertion length [in]
3.94 in
Insertion length [mm]
100 mm
Insertion type
Fixed
Number of terminals [pcs]
4 pc
Output signal
Ohm
Packing format
Multi pack
Process connection Male/Female
Male
Process connection material
Stainless steel
Process connection size
1/2
Process connection standard
ISO 228-1-A
Process connection type
G
Product group
Sensors
Product Name Description
Temperature sensor
Protection tube diameter [in]
0.315 in
Protection tube diameter [mm]
8 mm
Protection tube material
AISI 316 Ti
Quantity per packing format
8 pc
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
SCIP dossier no.
ab5a5d0b-78ac-4b3e-a6f6-bc20d26a29a6
Sensor elem. resistance [Ohm]
100
Sensor element [pc]
1 pc
Sensor element standard
EN 60751
Sensor element tolerance
Class A
Sensor element type
Pt
Sensor Insert
Exchangeable
Temperature range [=C2=B0C] [max]
200 =C2=B0C
Temperature range [=C2=B0C] [min]
-50 =C2=B0C
Temperature range [=C2=B0F] [max]
392 =C2=B0F
Temperature range [=C2=B0F] [min]
-58 =C2=B0F
Type
MBT 5252
Type designation
MBT 5252-0000-0100-0231-0000
UK RoHS compliance
Yes with exemptions
UK RoHS exemption clause
12,15,18,19,21
Wires [pcs]
4 pc
Temperature sensor overview for wholesaler Temperature sensors, type MBT 5250, MBT 5260 and MBT 5252 Temperature sensor type MBT 5252 Temperature sensor overview for wholesaler Danfoss EU-UK 084R1019.04 DEMKO 12CA69359 Pressure & Temperature Sensors Danfoss MD 084R1022.01 Danfoss MD 087R0017.01 ABS 22-2216869-PDA BV 06839-F0 BV DNV GL TAA000006F Rev. 3 KR DLN 34014-AE002 LR 2101288TA MBT 5252 Temperature sensors, TypeB, Pg16, G=C2=BD MBT 5252
