097B16379

Part Number: 097B16379
097B16379
Manufacturer
Danfoss
Part number
097B16379
Category

Product Information

Extended Description

097B16379 Danfoss: Refrigerants: R744, Compressor power supply [V]: 440-480V Y -3- 60Hz, Oil type: BOCKlub E85, Anti-vibration pads: No, Legacy BOCK ID: 16379
Gross weight
122.9 Kilogram
Net weight
111 Kilogram
Volume
237.223 Liter
EAN
5715162568118
Anti-vibration pads
No
Approval standard
No
Brand
BOCK
Capacity regulator
No
Colour
Blue (standard)
Compressor power supply [V]
440-480V Y -3- 60Hz
Contain batteries
No
Cylinder
4
Description
Compressor UL-HGX24/110 ML 10 CO2 T
Discharge connection size type
Standard
Discharge connection type
Blind flange
Family
UL CO2 T compressors
Frequency Hz
60
Hot gas temperature sensor
No
In scope of WEEE
No
Intermediate flange/adapter
No
IP class
IP 66
Legacy BOCK ID
16379
Length (mm)
738
Length [in]
23.38 in
Max pressure (PS) - high side
2176 psig
Max pressure (PS) - low side
1450 psig
Model number
UL-HGX24/110 ML 10 CO2 T
Motor protection
INT69 G 115-230V AC, 50/60 Hz, IP00
Oil sump heater
110-120V AC
Oil temperature sensor
No
Oil type
BOCKlub E85
Phase
3
Product group
Semi-hermetic compressors
Product Name Description
Reciprocating compressor HG
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Refrigerants
R744
SCIP dossier no.
aa816602-85c1-4b3d-a64b-18d375259a9f
SCIP dossier product name
HG(X)24/=E2=80=A6. CO2 T/LT
Screw-in valve
No
Suction connection size type
Standard
Suction connection type
Blind flange
Technology
Semi-hermetic CO2 transcritical
Terminal box reduced/steel TB
No
Thermal protection thermostat
No
Total height [in]
13.54 in
Type
UL-HGX24
Type designation
UL-HGX24/110 ML 10 CO2 T
U.S. EPA label
For installations using U.S. EPA restricted refrigerants, this product may be used for servicing existing equipment only.
Width [in]
13 41/50 in
