097C0957

Part Number: 097C0957
097C0957
Manufacturer
Danfoss
Part number
097C0957
Category

Product Information

Extended Description

097C0957 Danfoss: Refrigerants: R1270; R290, Compressor power supply [V]: 380-420V Y/YY -3- 50Hz PW, Oil type: BOCKlub G68, Anti-vibration pads: Yes, Legacy BOCK ID: 10998
Gross weight
237.711 Kilogram
Net weight
215.911 Kilogram
Volume
428.8 Liter
EAN
5715162650387
Anti-vibration pads
Yes
Applications
LBP,MBP,HBP
Approval standard
No
Brand
BOCK
Capacity regulator
No
Colour
Blue (standard)
Compressor power supply [V]
380-420V Y/YY -3- 50Hz PW
Contain batteries
No
Cylinder
6
Description
Compressor HG56e/995-4 S HC
Discharge connection size [in]
1 3/8 in
Discharge connection size [mm]
35 mm
Discharge connection size type
Standard
Discharge connection type
Soldering
Family
HC Compressors
Frequency Hz
50
Hot gas temperature sensor
No
In scope of WEEE
No
IP class
IP 66
Legacy BOCK ID
10998
Max pressure (PS) - high side
32 bar
Max pressure (PS) - low side
19 bar
Model number
HG56e/995-4 S HC
Motor protection
INT69 G 115-230V AC, 50/60 Hz, IP00
Oil differential pressure sensor
No
Oil pressure safety switch
No
Oil sump heater
220-240V AC
Oil temperature sensor
Pt1000
Oil type
BOCKlub G68
Phase
3
Product group
Semi-hermetic compressors
Product Name Description
Reciprocating compressor HG
Refrigerants
R1270,R290
Sound power @ 50Hz [db(A)]
86 dBA
Sound power @ 60Hz [db(A)]
86 dBA
Step protection for CR/SU
No
Suction connection size [in]
2 1/8 in
Suction connection size [mm]
54 mm
Suction connection size type
Standard
Suction connection type
Soldering
Technology
Semi-hermetic suction gas cooled
Thermal protection thermostat
No
Type
HG56e
Type designation
HG56e/995-4 S HC
U.S. EPA label
For installations using U.S. EPA restricted refrigerants, this product may be used for servicing existing equipment only.
Anti-vibration pads INT69 GTML=C2=AE Diagnose INT69 G=C2=AE Bock INT69 G=C2=AE Diagnose Maximum permissible inclination for Bock compressors O-ring selection One-third octave and Octave bands in dB for HG34e, HG44e, HG56e, HG66e and HG88e with R404A Torques for screwed connections Torques for screwed connections Assembly instruction for bearings semi-hermetic compressors BOCK compressors Semi-hermetic compressors, Reciprocating compressor HG, HG56e Semi-hermetic compressors, Reciprocating compressor HG, HG56e Semi-hermetic compressors, Reciprocating compressor HG, HG56e Semi-hermetic compressors, Reciprocating compressor HG, HG56e Semi-hermetic compressors, Reciprocating compressor HG, HG56e Semi-hermetic compressors, Reciprocating compressor HG, HG56e HG56e.STEP MC- HG56e, 14937 MC- HGX56e/850 S 25 LG, 1.0850-14937.0 BL.1-4 Semi-hermetic compressors, Reciprocating compressor HG, HGX56e
