097C6312

Part Number: 097C6312
097C6312
Manufacturer
Danfoss
Part number
097C6312
Category

Product Information

Extended Description

097C6312 Danfoss: Refrigerants: R404A; R407C; R452A; R134a; R407F; R513A; R448A; R450A; R449A, Compressor power supply [V]: 380-420V Y -3- 60Hz, Oil type: BOCKlub E55, Anti-vibration pads: Yes, Legacy BOCK ID: 17009
Gross weight
57.7 Kilogram
Net weight
48.3 Kilogram
Volume
152.46 Liter
EAN
5715162967867
Anti-vibration pads
Yes
Approval standard
No
Brand
BOCK
Colour
Blue - standard (conductive coating)
Compressor power supply [V]
380-420V Y -3- 60Hz
Contain batteries
No
Cylinder
2
Discharge connection size [in]
1/2 in
Discharge connection size [mm]
12 mm
Discharge connection size type
Standard
Discharge connection type
Soldering
Family
HG ATEX Compressors
Frequency Hz
60
In scope of WEEE
No
IP class
IP 66
Legacy BOCK ID
17009
Max pressure (PS) - high side
28 bar
Max pressure (PS) - low side
19 bar
Model number
EX-HGX12P/60-4 S
Motor protection
INT69 G 115-230V AC, 50/60 Hz, IP00
Oil sump heater
No
Oil type
BOCKlub E55
Product group
Semi-hermetic compressors
Product Name Description
Reciprocating compressor HG
Refrigerants
R134a,R404A,R407C,R407F,R448A,R449A,R450A,R452A,R513A
Suction connection size [in]
5/8 in
Suction connection size [mm]
16 mm
Suction connection size type
Standard
Suction connection type
Soldering
Technology
Semi-hermetic ATEX
Thermal protection thermostat
1
Type
EX-HG12P
Type designation
EX-HGX12P/60-4 S
U.S. EPA label
For installations using U.S. EPA restricted refrigerants, this product may be used for servicing existing equipment only.
