097C6351

Part Number: 097C6351
097C6351
Manufacturer
Danfoss
Part number
097C6351
Category

Product Information

Extended Description

097C6351 Danfoss: Refrigerants: R744, Compressor power supply [V]: 220-240V D / 380-420V Y -3- 60Hz, Oil type: BOCKlub E85, Anti-vibration pads: Yes, Legacy BOCK ID: 10957
Gross weight
59.7 Kilogram
Net weight
50.3 Kilogram
Volume
152.46 Liter
EAN
5715162972519
Adaptor decompression valve
No
Anti-vibration pads
Yes
Approval standard
No
Brand
BOCK
Colour
Blue (standard)
Compressor power supply [V]
220-240V D / 380-420V Y -3- 60Hz
Contain batteries
No
Cylinder
2
Discharge connection size [in]
1/2 in
Discharge connection size [mm]
12 mm
Discharge connection size type
Standard
Discharge connection type
Soldering/welding
Family
CO2 compressors
Frequency Hz
60
In scope of WEEE
No
IP class
IP 66
Legacy BOCK ID
10957
Max pressure (PS) - high side
55 bar
Max pressure (PS) - low side
40 bar
Model number
HGX12e/50-4 S CO2
Motor protection
INT69 G 115-230V AC, 50/60 Hz, IP00
Oil sump heater
110-240V AC
Oil type
BOCKlub E85
Product group
Semi-hermetic compressors
Product Name Description
Reciprocating compressor HG
Refrigerants
R744
Suction connection size [in]
5/8 in
Suction connection size [mm]
16 mm
Suction connection size type
Standard
Suction connection type
Soldering/welding
Technology
Semi-hermetic CO2 subcritical
Thermal protection thermostat
No
Type
HGX12e
Type designation
HGX12e/50-4 S CO2
U.S. EPA label
For installations using U.S. EPA restricted refrigerants, this product may be used for servicing existing equipment only.
