097C6874

Part Number: 097C6874
097C6874
Manufacturer
Danfoss
Part number
097C6874
Category

Product Information

Extended Description

097C6874 Danfoss: Refrigerants: R744, Compressor power supply [V]: 440-480V Y/YY -3- 60Hz PW, Oil type: BOCKlub E85, Anti-vibration pads: Yes, Legacy BOCK ID: 16565
Gross weight
525.6 Kilogram
Net weight
466.7 Kilogram
Volume
657.816 Liter
EAN
5715255013877
Anti-vibration pads
Yes
Approval standard
No
Brand
BOCK
Colour
Blue (standard)
Compressor power supply [V]
440-480V Y/YY -3- 60Hz PW
Contain batteries
No
Cylinder
6
Discharge connection size [in]
1 3/8 in
Discharge connection size [mm]
35 mm
Discharge connection size type
Standard
Discharge connection type
Soldering/welding
Family
CO2 LT compressors
Frequency Hz
60
Hot gas temperature sensor
No
IP class
IP 66
Legacy BOCK ID
16565
Max pressure (PS) - high side
100 bar
Max pressure (PS) - low side
100 bar
Model number
0
Motor protection
INT69 G 115-230V AC, 50/60 Hz, IP00
Oil differential pressure sensor
DELTA-P II 220-240V - 1 - 50/60 Hz
Oil level regulator
No
Oil service valve
No
Oil sump heater
220-240V AC
Oil temperature sensor
No
Oil type
BOCKlub E85
Product group
Semi-hermetic compressors
Product Name Description
Reciprocating compressor HG
Refrigerants
R744
Suction connection size [in]
1 5/8 in
Suction connection size [mm]
42 mm
Suction connection size type
Standard
Suction connection type
Soldering/welding
Technology
Semi-hermetic CO2 subcritical
Thermal protection thermostat
No
Type
HGX56e
Type designation
HGX56e/680-4 S CO2 LT
U.S. EPA label
For installations using U.S. EPA restricted refrigerants, this product may be used for servicing existing equipment only.
