114N3593
Part Number: 114N3593
Product Information
Extended Description
114N3593 Danfoss: Segment usage: Medium Back Pressure, Refrigerants: R404A; R452A; R134a; R448A; R449A, Compressor power supply [V]: 230/3/60
Gross weight
287 Kilogram
Net weight
269 Kilogram
Volume
1240.962 Liter
Air flow @ 60Hz [mÂł/h]
1400 mÂł/h
Applications
MBP
Approval
UL listed
Compressor model
MLZ076T2A
Compressor power supply [V]
230/3/60
Condenser type
Q8
Contain batteries
No
Description
OP-HRXM1000UWK000Q
Electrical code
Q
Family
Optyma™ Slim
Fan blade size [mm]
600 mm
Fan current @ 60Hz [A]
2.8 A
Fan diameter [mm]
600 mm
Fan power consumption @ 60Hz [W]
600 W
Fan power output @ 60Hz [W]
600 W
Fan power supply [V/Ph/Hz]
230/1/60
Fan voltage @ 60Hz (max) [V] [Min]
230 V
Frequency [Hz]
60 Hz
High value of nominal voltage at 60Hz [V]
230 V
Low value of voltage range at 60Hz [V]
208 V
Model number
OP-HRXM1000UWK000Q
Number of fans
2
Phase
3
Phases of Compressor
3
Phases of Fan
1
Product group
Condensing Units
Product Name Description
Package unit
Refrigerants
R448A,R449A,R134a,R404A,R452A
Segment usage
Medium Back Pressure
Speed Platform
Fixed-speed
Type
Optyma™ Slim WK
UL evaluated
Yes
Version
WK
119-4535
Tank, Receiver
119-4540
Condenser, Q8
119-4548
Connector, Service valve
119-4550
Connector, Service valve
119-4551
Connector, Service valve
119-4567
Electrical component, Starting relay
119-4652
Electrical component, Contactor
120Z0138
Crankcase heater, Crankcase heater
120Z0648
Lubricant, 215PZ
120Z5085
Acoustic hood, Scroll
