114X6001

Part Number: 114X6001
114X6001
Manufacturer
Danfoss
Part number
114X6001
Category

Product Information

Extended Description

114X6001 Danfoss: Segment usage: Medium Back Pressure, Refrigerants: R744, Compressor power supply [V]: 230/1/50, Mandatory accessory: Oil tank (118U4144) upon oil charge calculation method given inside application guideline
Gross weight
146 Kilogram
Net weight
114 Kilogram
Volume
1322.1 Liter
EAN
5702424493981
Accumulator volume [L]
2.5 L
Air flow @ 50Hz [mÂł/h]
1200 mÂł/h
Applications
MBP
Approval
CE
Capacity control
Inverter
CE evaluated
Yes
China RoHS compliance
Out of scope
Compressor model
CO2
Compressor power supply [V]
230/1/50
Connection type
Solder
Contain batteries
No
Description
OP-MPAM005COP04G
Design Pressure High [bar]
140 bar
Design Pressure Low [bar]
80 bar
Electrical code
G
EU RoHS compliance
Yes
EU RoHS exemption clause
No
Family
Optyma™ iCO2
Fan blade size [mm]
415 mm
Fan cowl/grill type
Cowl
Fan current @ 50Hz [A]
0.08 A
Fan diameter [mm]
415 mm
Fan power consumption @ 50Hz [W]
20 W
Fan power supply [V/Ph/Hz]
230/1/50
Fan voltage @ 50Hz (max) [V] [Max]
253 V
Fan voltage @ 50Hz (max) [V] [Min]
207 V
Frequency [Hz]
50 Hz
Gas cooler internal volume [L]
0.27 L
High value of nominal voltage at 60Hz [V]
253 V
Length [mm]
1350 mm
Liquid line connection [in]
3/8 in
Low value of voltage range at 60Hz [V]
207 V
Mandatory accessory
Oil tank (118U4144) upon oil charge calculation method given inside application guideline
Max pressure (PS) - high side
140 bar
Max pressure (PS) - low side
80 bar
MCC
15 A
Min fuse rating [A]
16 A
Model number
OP-MPAM005COP04G
No. of phases (compressor)
1
No. of phases (fan)
1
Number of fans
1
Number of receivers
2
PED category
I
Phase
1
Product group
Condensing Units
Product Name Description
Package unit
Receiver approval
CE
Receiver volume [L]
2.5 L
Refrigerants
R744
RLA
10 A
Segment usage
Medium Back Pressure
Sound pressure level 50Hz (@1 m distance) [db(A)]
56 dBA
Sound pressure level 50Hz (@10 m distance) [db(A)]
36 dBA
Speed Platform
Fixed-speed
Suction connection size [in]
3/8 in
Total height [mm]
834 mm
TS max
46 °C
TS min
-20 °C
Type
Optyma™ iCO2 P04
UK RoHS compliance
Yes
Version
P04
Voltage 50Hz [V]
207 V
Voltage 50Hz [V] [Max]
253 V
Width [mm]
480 mm
118U4100
Fan system, Fan grill
118U4129
Fan system, Fan assembly
118U4097
Housing, Sheet metal
118U4098
Housing, Sheet metal
118U4099
Housing, Sheet metal
118U4101
Housing, Sheet metal
118U4103
Tank, Receiver
118U4104
Tank, Accumulator
118U4105
Condensing Units Accessories & Spare parts, Compressor
118U4106
Connector, Valve
118U4144
Miscellaneous, Oil
DANFOSS Optyma iCO2 MBP - Refrigerant calculation sheet Optyma™ iCO2 condensing units - R744 | 50 Hz Convenience Store_CU Brochure Optyma iCO2 condensing units_eBrochure Optyma™ Packaged condensing units - Europe (EMA) Sound spectrum -OP-MPAM005COP04G Optyma™ iCO2 Condensing Units OP-MPAM005COP04G Basic Modbus parameter list Optyma™ iCO2 gateway (OP-MPAM015 and OP-MPAM005) CO2 solutions for small commercial cold rooms Danfoss DOI UK 118A4991.AB Danfoss EU-UK 118A5845.AA Condensers Danfoss MD 118A5047.AB Condensing unit Optyma iCO2 Condensing unit Optyma iCO2 Condensing unit Optyma iCO2 OP-MPAM005COP04G - STP
