115F0477
Part Number: 115F0477
Product Information
Extended Description
115F0477 Danfoss: Segment usage: Medium Back Pressure, Refrigerants: R404A, Compressor power supply [V]: 380/3/60
Gross weight
85 Kilogram
Net weight
72 Kilogram
Air flow @ 60Hz [m³/h]
6300 m³/h
Applications
MBP
Compressor model
MTZ040-4
Compressor power supply [V]
380/3/60
Condenser type
J8
Contain batteries
No
Description
OP-HJZ040D36V
Electrical code
V
Family
Optyma™
Fan current @ 60Hz [A]
2.6 A
Fan diameter [mm]
457 mm
Fan power consumption @ 60Hz [W]
450 W
Fan power supply [V/Ph/Hz]
230/1/60
Frequency [Hz]
60 Hz
High value of nominal voltage at 60Hz [V]
400 V
Low value of nominal voltage at 60Hz [V]
380 V
Model number
OP-HJZ040D36V
No. of phases (compressor)
3
No. of phases (fan)
1
Number of fans
1
Phase
3
Product group
Condensing Units
Product Name Description
Bare unit
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Refrigerants
R404A
Segment usage
Medium Back Pressure
Speed Platform
Fixed-speed
Technology
Reciprocating
Type
Optyma™ D36
Version
D36
118U601108
Tank, Receiver
191U007710
Tank, Oil separator
191U0644E
Condenser, J8
6804501V06
Connector, Service valve
191U006110
Tank, Accumulator
120Z0459
Crankcase heater, PTC heater
6804502V09
Connector, Service valve
191U9906
Miscellaneous, Filter
191U127667
Connector, Kit housing
7754001
Lubricant, 160P
