115F0512
Part Number: 115F0512
Product Information
Extended Description
115F0512 Danfoss: Segment usage: Low Back Pressure, Refrigerants: R404A; R452A, Compressor power supply [V]: 230/1/60
Gross weight
69 Kilogram
Net weight
60 Kilogram
Air flow @ 60Hz [mÂł/h]
2400 mÂł/h
Applications
LBP
Compressor model
NTZ068-1
Compressor power supply [V]
230/1/60
Condenser type
D8
Contain batteries
No
Description
OP-LJZ068D20N
Electrical code
N
Family
Optyma™
Fan blade size [mm]
350 mm
Fan current @ 60Hz [A]
1.1 A
Fan diameter [mm]
355 mm
Fan power consumption @ 50Hz [W]
200 W
Fan power consumption @ 60Hz [W]
240 W
Fan power output @ 60Hz [W]
240 W
Fan power supply [V/Ph/Hz]
230/1/60
Frequency [Hz]
60 Hz
High value of nominal voltage at 60Hz [V]
230 V
Low value of voltage range at 60Hz [V]
208 V
Model number
OP-LJZ068D20N
No. of phases (compressor)
1
No. of phases (fan)
1
Number of fans
1
Phase
1
Product group
Condensing Units
Product Name Description
Bare unit
Refrigerants
R404A,R452A
Segment usage
Low Back Pressure
Speed Platform
Fixed-speed
Technology
Reciprocating
Type
Optyma™ D20
Version
D20
Voltage 60Hz [V]
230 V
Condensing unit OPTYMA™ Lighter and more compact, fast installation and simple maintenance
Lighter and more compact Fast installation and easy maintenance OPTYMA™ Condensing Units - 50HZ
Condensing Unit Optyma™
Condensers
HJM/Z019 & HJM/Z022 & LJZ048 & LJZ068 D20
HJM/Z019 & HJM/Z022 & LJZ048 & LJZ068 D20
Condensing Unit - Optyma Commercial 1 - BR
LJZ068 D20
LJZ068 D20
