115F0643

Part Number: 115F0643
115F0643
Manufacturer
Danfoss
Part number
115F0643
Category

Product Information

Extended Description

115F0643 Danfoss: Segment usage: Medium Back Pressure, Refrigerants: R22, Compressor power supply [V]: 220/3/60
Gross weight
124 Kilogram
Net weight
112 Kilogram
Air flow @ 60Hz [m³/h]
7200 m³/h
Applications
MBP
Compressor model
MT050-3VM
Compressor power supply [V]
220/3/60
Condenser type
C4
Contain batteries
No
Description
HPMP050D20Q
Electrical code
Q
Family
Optyma™ Slim Pack
Fan current @ 60Hz [A]
1.94 A
Fan diameter [mm]
450 mm
Fan power consumption @ 60Hz [W]
130 W
Fan power output @ 60Hz [W]
260 W
Fan power supply [V/Ph/Hz]
230/1/60
Frequency [Hz]
60 Hz
High value of nominal voltage at 60Hz [V]
230 V
Low value of voltage range at 60Hz [V]
200 V
Model number
HPMP050D20Q
No. of phases (compressor)
3
No. of phases (fan)
1
Number of fans
1
Phase
3
Product group
Condensing Units
Product Name Description
Package unit
REACH Candidate List substances
Lead (CAS no. 7439-92-1)
Refrigerants
R22
Segment usage
Medium Back Pressure
Speed Platform
Fixed-speed
Technology
Reciprocating
Type
Optyma™ Slim Pack D20
Version
D20
191U13942E
Fan system, Fan blade
119-7401E
Fan system, Fan motor
MT50-3VI
Reciprocating compressor, MT50HK3CVE
118U3985E
Fan system, Fan grill
7754001
Lubricant, 160P
193U0592E
Condenser, C4
014L0174
SGP 16 N, Sight glass, Flare, 16.00 mm, Flare, 16.00 mm
023Z5045
Hermetic filter drier, DML, 16 cu.in., Steel
061F6067
Cartridge pressure switch, ACB, 26.50 bar, 20.50 bar
