115F0652
Part Number: 115F0652
Product Information
Extended Description
115F0652 Danfoss: Segment usage: Medium Back Pressure, Refrigerants: R404A; R452A; R134a; R513A; R448A; R449A, Compressor power supply [V]: 230/3/60
Gross weight
96 Kilogram
Net weight
83 Kilogram
Air flow @ 60Hz [mÂł/h]
6300 mÂł/h
Applications
MBP,HBP
Compressor power supply [V]
230/3/60
Condenser type
J8
Contain batteries
No
Description
HJZ064D36Q
Electrical code
Q
Family
Optyma™
Fan diameter [mm]
457 mm
Fan power consumption @ 60Hz [W]
450 W
Fan power supply [V/Ph/Hz]
230/1/60
Frequency [Hz]
60 Hz
High value of nominal voltage at 60Hz [V]
230 V
Low value of voltage range at 60Hz [V]
200 V
Model number
HJZ064D36Q
No. of phases (compressor)
3
No. of phases (fan)
1
Number of fans
1
Phase
3
Product group
Condensing Units
Product Name Description
Bare unit
Refrigerants
R134a,R404A,R448A,R449A,R452A,R513A
Segment usage
Medium Back Pressure
Speed Platform
Fixed-speed
Type
Optyma™ D36
Version
D36
118U601108
Tank, Receiver
120Z0459
Crankcase heater, PTC heater
120Z0638
Lubricant, 175PZ
191U006310
Tank, Accumulator
191U007710
Tank, Oil separator
191U0644E
Condenser, J8
191U127667
Connector, Kit housing
191U9907
Miscellaneous, Filter
6804501V06
Connector, Service valve
6804503V04
Connector, Service valve
